Machinery Part Replacement Z Unit (3-nozzle type) Remarks Item * Only when removing, take this step. 7 5 Do not move the dog. Feeler gauge See Section "6-2-5 3-Head Support Regulator Replacement." See Sections …

100%1 / 1093
Machinery Part Replacement
Z Unit (3-nozzle type)
Remarks
3
4
Install the high-speed head
Remove the stopper block.
See "Section 5-5-1.
Replacing a Set of Head
Units."
BLOCK：KXFB02KDA00
2 pcs.
See Section "5-3-1
Transfer Head Assembly
Replacement"
2
1
head.
Item
Remove the multi-purpose
Switch off the power and air supply.
1
2
Multi-purpose head
High-speed head
EJM8A-E-SMA050504-A01-00
Page　5-5-4-2
Machinery Part Replacement
Z Unit (3-nozzle type)
RemarksItem
* Only when removing, take this step.
7
5
Do not move the dog.
Feeler gauge
See Section "6-2-5 3-Head
Support Regulator
Replacement."
See Sections "6-3-1.
Installing the Lead
Checker"
amplifier.
6
* Only when removing, take this step.
8
Remove the electropneumatic regulator.
Adjust the collision preventing photo sensor so that it turns ON when the gap of the
collision preventing stopper and the X beam is 0.5 mm.
Remove the lead checker sensor
sensor dog.
Precisely position the Y-axis interference Move it down to the other end of the cut.
0.5
Multi-purpose
High-speed
[Multi-purpose head]
[High-speed head]
Collision preventing
stopper
PH bracket
Dog
Dog
PH bracket
Collision preventing
stopper
0.5
EJM8A-E-SMA050504-A01-00
Page　5-5-4-3
Remarks
* Only when removing, take this step.Remove the laser board.
Remove the multi-purpose nozzle
See Sections "6-1-3.
Adding a Lead Checker"
See Section "6-2-3.
Nozzle Changer
Replacement (Multi-
Purpose Machines)."
Remove the cable.
* Only when removing, take this step.
changer.
Machinery Part Replacement
Z Unit (3-nozzle type)
Item
See Section "6-1-3.
Nozzle Changer
Replacement (High-speed
Machines)."
Install the high-speed nozzle changer.
10
11
9
12
CPUBOX
Multi-purpose head
High-speed head
Amplifier
Sensor
EJM8A-E-SMA050504-A01-00
Page　5-5-4-4
