No. Jig/tool name and Module name Qty. Purpose Part no. CM602 1 Component-height-detection- sensor-adjusting power source (without amplifier) 1 Power source for amplifier of 8- nozzle-head component- thickness-measuring …
6-6-1 List of Jigs and Tools
Jigs and Inspection DevicesOption Part and Accessory Replacement
Ji
g
s and Ins
p
ection Devices
6-6
1. List of special jigs and tools ................................................. P. 2 - 3
• This section describes the special jigs and tools that are used for installing, adjusting and teaching the
component-thickness-measuring unit and PCB-warp sensor.
EJM8A-E-SMA060601-A01-00
Page 6-6-1-1
No.
Jig/tool name and Module name
Qty. Purpose Part no.
CM602
1
Component-height-detection-
sensor-adjusting power source
(without amplifier)
1
Power source for amplifier of 8-
nozzle-head component-
thickness-measuring unit
N610047800AA O
2
Component-height-detection-
sensor-adjusting power source
1
Power source for amplifier of 12-
nozzle-head component-
thickness-measuring unit (fixed)
N610034340AA O
3
Component-thickness-sensor-
light-axis-adjusting jig
1
12-nozzle-head light-axis
adjustment
N610034346AA O
4
Component-thickness-
measuring-unit-light-axis-
adjusting jig
1
8-nozzle-head light-axis
adjustment
N610019723AA O
5 Installation adjusting jig 1
PCB-height-measuring-sensor-
installing adjustment
N610047825AA O
6 Height measuring jig 1
PCB-height-measuring-sensor
calibration
N610051789AA O
Jigs and Inspection Devices
FM-1963
August 5, 2006
Option Part and Accessory Replacement
FM-1964
FM-1962(2)
FM-1853(2)
(Installing, adjusting and teaching the component-thickness-measuring unit and PCB-warp sensor.
FM-1853(1)
Adm. code
FM-1962(1)
EJM8A-E-SMA060601-A01-00
Page 6-6-1-2
No. Jig/Tool No. Jig/Tool
12
Adm. code Adm. code
FM-1962(1) FM-1853(1)
Name Name
N610047800AA N610034340AA
No. Jig/Tool No. Jig/Tool
34
Adm. code Adm. code
FM-1853(2) FM-1962(2)
Name
Name
N610034346AA N610019723AA
No. Jig/Tool No. Jig/Tool
56
Adm. code Adm. code
FM-1963 FM-1964
Name Name
N610047825AA N610051789AA
Installation
adjusting jig
Height
measuring jig
Component-
thickness-
sensor-light-
axis-adjusting
jig
Component-
thickness-
measuring-
unit-light-axis-
adjusting jig
Jigs and Inspection Devices
Option Part and Accessory Replacement
Component-
height-
detection-
sensor-
adjusting power
source (without
amplifier)
Component-
height-
detection-
sensor-
adjusting
power
source
EJM8A-E-SMA060601-A01-00 Page 6-6-1-3
