Adjustable distance: +/- 3 mm (The hole is 3-mm long.) Tray Shuttle Tray Item Remarks 13 Switch on the power. Fit the jig on the door switch connector. 15 Distance from Dog to Stopper: 9.5 ㎜ ±1 ㎜ 14 Measure the distance …
Tray Shuttle Tray
Adjust the belt tension.
Allen key 3 mm
Allen key 4 mm
Screw M4 2 pcs.
Screw M5 2 pcs.
Allen key 3 mm
Allen key 4 mm
Screw M4 2 pcs.
Screw M5 2 pcs.
Remarks
Replace the belt.
Put the motor shaft holder back on.
Allen key 3 mm
M4 2 pcs.
12
9
Remove the motor shaft holder.
Put the pickup head belt clamp back on.
Loosen the tension and remove the belt.
10
11
Item
Motor shaft holder
EJM8A-E-SMA070108-A01-00
Page 7-1-8-4
Adjustable distance: +/- 3 mm
(The hole is 3-mm long.)
Tray Shuttle Tray
Item Remarks
13
Switch on the power.
Fit the jig on the door switch
connector.
15
Distance from Dog to
Stopper:
9.5㎜±1㎜
14
Measure the distance from the dog to the mechanical stopper.
Allen key 3 mm
Screw M4 2 pcs.
If it is necessary to adjust the distance, loosen the bolts that are positioned
at the back of the belt clamp, and adjust the distance.
16
Carry out "Return to origin."
(Be sure to keep yourself off the drive section.)
3
6.5
36.5
(30)
4.5
731.5
727st
－O/R
StrokeOrigin
＋O/R
Mechanical
stopper
Dog
＋soft limit
－soft limit
EJM8A-E-SMA070108-A01-00
Page 7-1-8-5
12
34
Remarks
loosen the bolts below and move the belt.
Shuttle TrayTray
Allen key 3 mm
Screw M4 2 pcs.
If it is necessary to adjust the distance more than 3 mm,
19
20
Item
18
17
Carry out "Return to origin." Check the distance.
Remove the jig from the door
switch connector.
Allen key 3 mm
M4×8L 3 pcs.
M4×10L 2 pcs.
M4×12L 2 pcs.
Put the cover back on the motor section.
30
B
A=727st
(770)
C
D
E
EJM8A-E-SMA070108-A01-00
Page 7-1-8-6
