Auto train Inspection Result (Upon Inspection)

When the inspection is 100% completed, an Auto Train result appears in inspection

list. The auto train results are:

● Total component trained

● Auto train result in table

● Last modified date

● Total time taken

In the auto train results, there are two types of important information which are the

total component trained and the auto train result in table. In the auto train result, there

are two highlighted colors are green and red. The row in green represents the part

number which has successfully auto trained while row in red represents the part

number failed to auto train. The AI column contains the training detail log.

116

Figure 105: Auto train result

Note of Smart train

Smart train is a feature that applied Artificial Intelligence

(A.I) technology. This feature is specifically used to train

components in a manual way in one click by using A.I

technology. The following figure shows Smart Train

interface in algorithm trainer. There are three parts

under Smart Train which are:

● A.I Train

● A.I Train by manual package selection

● IPC Class

Note: Smart train option is shown when the A.I smart

programming license is detected by the ViTrox license

server and with the existence of .plx, .eplx and .epad

files in the c:/cpi/cad folder. Contact the ViTrox AOI

Service and Support team to learn about the A.I smart

programming license.

117

Figure 106: Smart train interface

Negative Test (Upon Inspection)

Negative test is a quality checking tool of component orientation in the program that includes:

● Test and measure the program quality

● Reduce false calls and escapee rate

● Reduce CAD errors

Note: Negative test must be applied to a good board.
