Algorithm Editor Interface
166
Figure 155: Algorithm Editor Interface
Component Tree View
Display View
Editor Tool
Inspection Result
Display Result
A.I Technology Status
Algorithm Parameter Fine Tuning
View Mode
Program Name
Detail of Ref. Des.
Copyright © ViTrox All Rights Reserved.
Editor Tool
Note: User can select any feature to use for inspect the ref. des.
167
Inspect
Inspect for respective Ref. Des.
Inspect and camera not capture
Inspect and camera will capture again
Inspect all part number and camera not capture
Inspect all part number and camera will capture again
Figure 156: Inspect Feature
Copyright © ViTrox All Rights Reserved.
Editor Tool
Note: To Inspect all the reference designator for current fine tuning.
168
Visit All and Inspect
Visit and Inspect all reference
designator under this device type in
panel board.
