General Setting

Console Output is used to display the results of various calibration procedures, such as R & R tests. This is also used for

development and troubleshooting purposes. This feature displays the console done in back-end service such as component

inspection, fiducial inspection, training and etc.

Note: Opening console output and run inspection will gradually increase cycle time.

Console Output

Show Console Output

Figure 10: Console Output

General Setting

The system saves the report files in numerical order, from 1 to an upper limit that a user specified in the config.txt file. When the

system reaches the upper limit, it returns back to 1. Pressing Reset Report File Count sets the system so that the next inspection

comes with the rep file number 001. This can be seen in the program information.

Reset Report File Count

Figure 11: After reset-ing report file count

General Setting

Pressing System Information brings up the dialogue box shown in the figure below. It also writes the C:\cpi\log\about_gsi.txt file. This

may be required for troubleshooting. This includes information such as the camera's pixel size.

Note: X view of size (15.0 microns) represent a 15 μm lens and the viewport (4096 x 3072 pixels) represents a 12M camera.

System Info

Show System Information

Figure 12: Show System Information
