Train Interface
140
Copyright © ViTrox All Rights Reserved.
Train Interface
141
List of Tool Box
Untrained/ Train Tree View
List of of Algorithm Assigned
Smart Train Feature
Trainer Main Button
Log of Train History
Switch Mode View
Display Area
Status of device type
Figure 128: Main Display Train Interface
Copyright © ViTrox All Rights Reserved.
Train Interface (Untrained/Train Tree View)
142
Figure 129: List of Component Tree
Component Tree View
Component Train View
Component Defect List
