Smart Graphical User Interface (SmartG) Overview_rev1.pdf - 第169页
Copyright © ViT rox All Rights Reserved . Editor T ool Note: User can select any ref des with same device type 169 Next Go to next ref. des. under same device type Figure 157: Sample of List ref des.
Copyright © ViTrox All Rights Reserved.
Editor Tool
Note: To Inspect all the reference designator for current fine tuning.
168
Visit All and Inspect
Visit and Inspect all reference
designator under this device type in
panel board.
Copyright © ViTrox All Rights Reserved.
Editor Tool
Note: User can select any ref des with same device type
169
Next
Go to next ref. des. under same
device type
Figure 157: Sample of List ref des.
Copyright © ViTrox All Rights Reserved.
Editor Tool
Note: User can select any angle plane to change the view of display of the components.
170
Plane
Switch Image Plane
Figure 158: List of Image Plane
