General Setting (Engineer Setting)

Turn On Sampling Inspection

This feature is used to run the sampling inspection for the

first and second program, or vise versa. Set the sampling

inspection to On, and click the sampling inspection button

as shown in the figure below.

Note: This feature is applicable to single lane and dual

lane.

Figure 23: Engineer Settings

Figure 24: Dual file sampling inspection setup

1) Load the PLX file for first and second program

2) Set the quantity of first and second program

and click at add button.

3) After add, the information will be added in the

table.

General Setting (Action on Failure Options)

Action on Failure Options are used to set up the operator access control and use model in the operator mode. The

options are:

● Allow board selection in operator

● No action on failure for operators

● Allow operators mark false fail

● Force operator to look at all errors

● Allow no reason for false fail

● Allow no MVC fail

Figure 25: Action on failure options

General Setting (Action on Failure Options)

This feature is designed to allow change of

program in Operator mode.

Figure 26: Action on failure options

Allow board selection in Operator
