Copyright © ViT rox All Rights Reserved . Editor T ool 171 Mask Perform masking on certain location of component Figure 159: List of feature in Masking Mask specific Joint Errors Mask the bridging error Note: All the mas…

Editor Tool

Note: User can select any angle plane to change the view of display of the components.

170

Plane

Switch Image Plane

Figure 158: List of Image Plane

Editor Tool

171

Mask

Perform masking on certain location

of component

Figure 159: List of feature in Masking

Mask specific Joint Errors

Mask the bridging error

Note: All the masking will not be inspected.

Mask side fillet errors

All the error can be mask

Clear all the mask

Editor Tool

172

Skip

Skip Component.

Note: All the selected skip components will be skip inspection

Modify

Modify orientation and offset of this

component.

Save

Save all the fine tuning modification

Note: To Modify current ref des for orientation and offset

Note: To save all the modifications
