Copyright © ViTrox All Rights Reserved.
Zoom in Selected region
Note: User can drag any region to zoom in whether components or boards.
96
Zoom in Selected
Region
Zoom in with specific location or
components.
Figure 83: Example ‘yellow’ Selected region to zoom in
Copyright © ViTrox All Rights Reserved.
Zoom In,Zoom Out
Note: User can use mouse wheel to zoom in and out at any location
97
Zoom in (+), Zoom Out (-)
Zoom in the camera view
Figure 84: Zoom in/Zoom out to specific pointed mouse
Copyright © ViTrox All Rights Reserved.
View origin Location
View origin location is used display full-board view and the original location. When clicking the View Origin Location
button in the tool box, the camera view always moves to the original location of the board.
98
View Origin Location
View the origin location of the panel
board
