Copyright © ViTrox All Rights Reserved.
Machine Setting (Barcode)
59
Figure 49: General Setting (Barcode) Parameter in SmartG
1
To enable barcode
validator from MES
To prompt out the
message fail as barcode
if the barcode is fail.
Copyright © ViTrox All Rights Reserved.
Machine Setting (Barcode)
60
User can use this if the
barcode file already exists in
the PC
2
Please ensure COM port in
device manager is tally with
this serial ports number.
Communication Channel
*Please ensure these
communication channel is
tally with configuration
application barcode
software.
Figure 50: Reader Specific (Barcode) Parameter in SmartG
Please use
this symbol
“<+>”
This box to ensure the
barcode configuration
in good condition
Barcode Initialised Successfully
Copyright © ViTrox All Rights Reserved.
Machine Setting (Barcode)
61
2 options:
● Use Board Specific Setting (User can Import file .brc to run this feature)
● Use Machine Settings (User can use this configuration machine barcode setting)
Figure 51: Reader Specific (Barcode) Parameter in SmartG
3
