Copyright © ViT rox All Rights Reserved . Algorithm Setting (Algorithm Editing) 80 Figure 65: Algorithm Editing Parameter in SmartG 1 2 3 4 5 6 7 8 9
Copyright © ViTrox All Rights Reserved.
79
Algorithm Setting
Copyright © ViTrox All Rights Reserved.
Algorithm Setting (Algorithm Editing)
80
Figure 65: Algorithm Editing Parameter in SmartG
1
2
3
4
5
6
7
8
9
Copyright © ViTrox All Rights Reserved.
Algorithm Setting (Algorithm Editing)
Note: Please refer to slide Algorithm for more information and detail
81
1
2
To improve CR type defect specification
To enable/disable motorized Z height
*depend on the machine
To enable/disable periodic checking
To enable/disable Optical Character
Verification for inspection
To enable/disable Optical Character
Verification for inspection
*In default, this feature already enable
To enable/disable the warning message
if OCV is fail or missing
To enable/disable Optical Colour
Inspection
Figure 66: Algorithm Parameter
Figure 67: OCV and OCI Parameter
