Assembly and Instruction Manual 1 Introduction
Shuttle Extension Edition 11/2018 1.3 Technical data
15
1.3 Technical data
1
Dimensions shuttle extension (see in fig. 1.4 - 1, page 16)
Length 1 440 mm
Width 1 691.6 mm
Height at a conveyor height of 950 mm 1 1162.5 mm
Weight 1 80 kg
Dimensions shuttle extension with barcode reader extension (see in fig. 7.1 - 2
, page 74)
Length 1 647 mm
Width 1 691.6 mm
Height at a conveyor height of 950 mm 1 1162.5 mm
Weight 1 105 kg
Overall
Nominal voltage 42 V and 24 V
Full-load current 0.8 A and 1.5 A
Max. noise emissions 75 dB (A)
Ampere rating of largest motor 2 A
Short circuit rating of machine (SCCR) 0.5 kA
Power 0.033 kW and 0.036 kW
PCB thickness 0.3 mm to 4.5 mm
PCB width
Single conveyor 1 45 mm to 460 mm
Dual conveyor 1 45 mm to 260 mm
PCB length 45 mm to 375 mm
PCB weight Max. 2 kg
PCB detection LED light barriers
TX conveyor rail positions/PCB width
Transport rail position 231 => Distance between
fixed rail (outer position) 462 mm
=> PCB width
210 mm
Transport rail position 268
=> Distance between
fixed rail (outer position) 536 mm
=> PCB width
250 mm
Transport rail position 281
=> Distance between
fixed rail (outer position) 562 mm
=> PCB width
260 mm
1 Introduction Assembly and Instruction Manual SIPLACE TX
1.4 Ambient conditions and connection values Shuttle Extension Edition 11/2018
16
1.4 Ambient conditions and connection values
1.4.1 Ambient conditions for packaging, transportation and storage
1
1.4.2 Ambient conditions for machine operation
1
1.4.3 Footprint
1
Fig. 1.4 - 1 Shuttle extension footprint
(1) Width
(2) Length
(3) Height
Temperature range Between -25°C and 55°C
Atmospheric humidity Up to 95%
Ambient pressure Up to 1700 m height without pressure equalization
Room temperature Between 15°C and 35°C
Atmospheric humidity 30% to 75% (on average not higher than 45%, so that there is
no risk of condensation on the machine.)
Ambient pressure > 750 mbar (corresponds to 2500 m above mean sea level)
