Assembly and Instruction Manual 1 Introduction Shuttle Extension Edition 11/2018 1.5 Important notes on the instruction manual 17 1.5 Important notes on the instruction manual 1.5.1 Contents and filing of the instruction…
1 Introduction Assembly and Instruction Manual SIPLACE TX
1.4 Ambient conditions and connection values Shuttle Extension Edition 11/2018
16
1.4 Ambient conditions and connection values
1.4.1 Ambient conditions for packaging, transportation and storage
1
1.4.2 Ambient conditions for machine operation
1
1.4.3 Footprint
1
Fig. 1.4 - 1 Shuttle extension footprint
(1) Width
(2) Length
(3) Height
Temperature range Between -25°C and 55°C
Atmospheric humidity Up to 95%
Ambient pressure Up to 1700 m height without pressure equalization
Room temperature Between 15°C and 35°C
Atmospheric humidity 30% to 75% (on average not higher than 45%, so that there is
no risk of condensation on the machine.)
Ambient pressure > 750 mbar (corresponds to 2500 m above mean sea level)
Assembly and Instruction Manual 1 Introduction
Shuttle Extension Edition 11/2018 1.5 Important notes on the instruction manual
17
1.5 Important notes on the instruction manual
1.5.1 Contents and filing of the instruction manual
This manual contains information that must be observed when installing, setting up and operating
the shuttle extension. The service engineers, qualified staff, operators and users plus system
owner must therefore read it before commencing installation and commissioning. The instructions
must be kept permanently accessible where the shuttle extension is used.
In addition, the user must ensure that the employees have fully understood the contents of this
manual.
1.5.2 Danger notes
1
1.5.3 Manufacturer's/supplier's liability
We hereby confirm that the contents of this manual are of a descriptive and explanatory nature
only and do not contain any contractual conditions or guaranties. The liability and obligations as
-
sumed by ASM Assembly Systems GmbH&Co.KG can be found exclusively in the relevant con
-
tract agreement concerning the supply of the shuttle extension described in this manual. This
applies in particular to all statements regarding performance or service life and the agreed liability
for faults or defects. The provisions of the contract regarding the liability for faults or defect are
neither extended nor restricted by any statements in this manual.
WARNING
Read the instruction manual!
Tasks may only be performed by qualified staff who have completed the relevant
training.
Only perform tasks on the SIPLACE machines if you have precise knowledge of the
corresponding section in the relevant instruction manual (SIPLACE TX, SIPLACE
SX1/SX2 V2).
Only perform tasks on the shuttle extension if you have precise knowledge of the rel
-
evant section in this manual.
Observe all warnings, caution notes and hazard notes.
Please also read chapter 2 of this manual through carefully.
1 Introduction Assembly and Instruction Manual SIPLACE TX
1.5 Important notes on the instruction manual Shuttle Extension Edition 11/2018
18
1.5.4 Revision table
1
1.5.5 Further information
1.5.5.1 How to get information
If you have any further questions concerning this manual or if you would like additional information
on a particular topic, please get in touch with your local SIPLACE dealer or contact us directly at:
ASM Assembly Systems Singapore Pte Ltd
535 Yishun Industrial Park A
ASM Tech-Park Building 2
Singapore 768775 1
1.5.5.2 SIPLACE on the World Wide Web (WWW)
We also have our own site on the Internet. Why not log into our homepage at http://www.asm-smt-
solutions.com.
All the menus and other information are available in two languages: You can choose between the
German and English versions.
The various headings contain information on
– Our products
– Services
– Contacts, etc.
Registered customers can also access the SIPLACE User Group. There you can call up special
information on our placement machines, such as
– Technical documentation
– Technical information
– Spare parts catalogs etc.
Edition Amendments
12/2016 – First edition
06/2017 – Update version
– Barcode reader extension
– Formal adjustments
11/2018 – Update version
– Shuttle extension on the SIPLACE SX1/SX2
– Formal adjustments
