Assembly and Instruction Manual 7 Barcode reader extension Shuttle Extension Edition 11/2018 7.3 Scope of delivery 77 7.3 Scope of delivery – Barcode read er extension kit cpl.: [Item no.: 03158729-xx] – Extensi on 207_r…
7 Barcode reader extension Assembly and Instruction Manual
7.2 Safety Shuttle Extension Edition 11/2018
76
7.2.1.1 Warning label W 203
7
W 203 in fig. 7.2 - 1, page 75, item no. 03009342-01
(Quantity per barcode reader extension: 2)
7.2.2 Classification of optical systems
7
7
7
7
Danger of crushing
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the shuttle extension - barcode reader ex
-
tension while it is running.
Do not reach into the inside of the neighboring shuttle exten
-
sion.
PLEASE NOTE
Laser class 1
The barcode readers used has bright LEDs fitted. These are classified as laser class 1,
according to
DIN EN 60825-1-2014-05.
Do not look into beam!
Assembly and Instruction Manual 7 Barcode reader extension
Shuttle Extension Edition 11/2018 7.3 Scope of delivery
77
7.3 Scope of delivery
– Barcode reader extension kit cpl.: [Item no.: 03158729-xx]
– Extension 207_right cpl. (prefitted) [Item no.: 03149504-xx]
– Extension 207_left cpl. (prefitted) [Item no.: 03149503-xx]
– Barcode reader ext. Cover BG[Item no.: 03135848-xx]
– ISO 7380-2 M 4 x 10-A2-70 [Item no.: 03099579-xx]
– Safety mark 9 x 600 mm [Item no.: 03153427-xx]
– ISO 7093-1 - 5 - 200 HV - A2 [Item no.: 03022708-xx]
– ISO 4762 - M 5 x 10-A2-70 [Item no.: 03042560-xx]
– ISO 4762 - M 5 x 6-A2-70 [Item no.: 03082905-xx]
– Klettostar velcro fastening 90 mm [Item no.: 03157157-xx]
– Ethernet Switch 5-port with modif. Cable [Item no.: 03152110-xx]
– Cable: BC scanner power pack and control [Item no.: 03123643-xx]
– Cable: Control computer LAN 3 [Item no.: 03148161-xx]
– RJ45 adapter snap-in Bu - Bu shielded [Item no.: 03098672-xx]
– LAN card PCI Express 2x Gigabit LAN [Item no.: 03118416-xx]
– Cable: LAN PC - adapter - shuttle TX [Item no.: 03152764-xx]
– Ground cable for shuttle top cover [Item no.: 03151850-xx]
7.3.1 Overview - barcode reader extension kit assy.
Fig. 7.3 - 1 Barcode reader extension kit assy.
7 Barcode reader extension Assembly and Instruction Manual
7.3 Scope of delivery Shuttle Extension Edition 11/2018
78
7.3.2 Shuttle extension loose parts
– Plug d24.8 D31.5 LDPE normal [Item no.: 03154892-0101
7
7
Fig. 7.3 - 2 Remove the barrel plug
PLEASE NOTE
Remove the barrel plug
When the barcode reader extension is integrated onto the shuttle extension, this barrel
plug must be removed to allow cables routing.
03154892-0101
