Assembly and Instruction Manual 2 Oper ational safety Shuttle Extension Edition 11/2018 2.2 Warning labels 27 Fig. 2.2 - 4 Warning labels insi de the shuttle extension - part 2 (1) Warning strips on the h and guard Item …
2 Operational safety Assembly and Instruction Manual
2.2 Warning labels Shuttle Extension Edition 11/2018
26
Fig. 2.2 - 3 Warning labels inside the shuttle extension - part 1
(1) Ground
(T) Direction of PCB transport
(1)
Assembly and Instruction Manual 2 Operational safety
Shuttle Extension Edition 11/2018 2.2 Warning labels
27
Fig. 2.2 - 4 Warning labels inside the shuttle extension - part 2
(1) Warning strips on the hand guard
Item W 203, item no. 03009342-xx
2
WARNING
Damage to warning labels!
The warning labels can be damaged or destroyed by abrasive cleaning agents or sol
-
vents.
Do not use abrasive cleaners or solvents for cleaning warning labels.
Replace any damaged or illegible warning labels.
(1)
W 203
W 203
2 Operational safety Assembly and Instruction Manual
2.2 Warning labels Shuttle Extension Edition 11/2018
28
2.2.1 Warning label W 203
2
W 203 in fig. 2.2 - 1, page 24, 2.2 - 2, page 25 and 2.2 - 4, page 27, item no. 03009342-01
(Quantity per shuttle extension: 8)
2.2.2 Warning label W 204
2
W 204 in fig. 2.2 - 1, page 24 and 2.2 - 2 page 25, Item no. 03009343-01
(Quantity per shuttle extension: 2)
2.2.3 Warning label W 210
2
W 210 in fig. 2.2 - 1, page 24, item no. 03009350-01
(Quantity per shuttle extension: 1)
2
2
2
Danger of crushing
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the shuttle extension while it is running.
Do not reach into the inside of the neighboring machine.
2
2
2
Danger of crushing
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the shuttle extension while it is running.
2
2
2
2
2
2
Warning label on the EMERGENCY STOP button
