Parts Replacement 9-7
10. Bring the two ends of the chain one chain-link length apart (Figure 9-8).
11. Insert master link’s male link into both ends of the chain so that pins are pointing outboard
(Figure 9-8).
12. Attach the master link’s female link to both male link’s pins (Figure 9-9).
13. Slide the retainer clip onto male link’s pins. Ensure that the clip’s open end points in the
direction of the motor subassembly (Figure 9-10).
Figure 9-8 Inserting the Male
Link
Figure 9-9 Attaching the
Female Link
Figure 9-10 Installing the
Retainer Clip
14. Tension the chain by loosening the motor mounting screws allowing the motor’s weight to
remove the slack.
NOTE Slack should be eliminated with the motor’s weight (do not push the motor
down to create tension on the chain).
15. Perform a visual inspection of chain to ensure that slack from chain is eliminated.
16. Lock motor into position by tightening screws.
17. Perform a function check by revolving the chain 2 to 3 times through its complete range
of motion.
18. Replace any rail-mounted equipment that you removed in Step 6.
19. Repeat Steps 7-18 for the remaining chain.
20. Replace any coating system panels you may have removed.
9-8 Parts Replacement
9.9 Replacing the Camera Lens
CAUTION! Except for lens replacement and lighting adjustments, all other configuration and
adjustments should only be performed by a trained service technician.
To remove and replace the camera lens:
1. Remove the lens by turning the lens tube counterclockwise (Figure 9-11).
2. Screw on the replacement lens by turning the lens tube clockwise.
Item Description
1 Camera
2 Lens Tube
Figure 9-11 Replacing the Camera Lens
2
1
Parts Replacement 9-9
9.10 Replacing Fuses
If your Select Coat SL-940E/SL-941E is equipped with a heated fluid system, there are two replaceable
fuses. See Table 9-1.
CAUTION! Always replace fuses with fuses of identical rating and size. Failure to do so may
not protect components from damage.
9.10.1 Replacement Fuses
Table 9-1 Replacement Fuses
Part Number Qty. Description Location
55-5391 1 FUSE, 4A, 5X20MM, TIME LAG Fluid System Heater
Tools and Materials Needed
•
ESD Grounding Strap
•
Replacement Fuse (see Table 9-1)
• Small Flat Head Screwdriver* • Phillips Screwdriver*
WARNING! CAUTION!
Fuse replacement should be performed by a trained service technician only.
