Appendix C - Parts List C-1
Appendix C Parts List
C.1 Overview
This section includes general information for ordering recommended spares and replacement parts for the
SL-940E Series Conformal Coating System. Table C-1 lists available spare parts kits and part numbers.
Part number information is also available on Asymtek’s Find-A-Part web page:
http://webstore.asymtek.com/awweblive/apps/findapart_index.asp
C.2 Safety First
Before attempting to replace any parts, please review the precautions in Section 2 - Safety.
CAUTION! Only service technicians should perform troubleshooting, servicing, and parts
replacement.
C.3 Spare Parts Kits
Table C-1 contains a list of spare parts that will aid in ordering replacements parts for the SL-940E/SL-941E
Series Conformal Coating System.
NOTE Parts listed in Table C-1 are those in effect at the time of manual publication. Part number
information is also available on Asymtek’s Find-A-Part web page:
http://webstore.asymtek.com/awweblive/apps/findapart_index.asp
C-2 Appendix C - Parts List
Table C-1 Spare Parts List
Part Number Description
7209606-2 Cable, 940 Light Source
7209631 Cable, Hi flex CAT6 shielded
7210782-1 Cable, Valve
7210783-1 Cable, Dispense Solenoids
7210785-1 Cable, Dispense Sensors
7204931 Assy, Board Pin, 30mm
198799 Assy, Stop Pin
7207835 Chain, #25 340 Link
7210974 Assy Board Sensor
7209437 Assy, Main Air Regulator
7211533 Assy, Fluid Regulator, 940
7209435 Spring, Gas, 90lb
7207355 PWA, Home Sensor
115810 Cup,SS,125ml
7215968 Assy, Vent Switch,.15-55" W.C.
7216553 Assy, Regulator, E/P, 0-130psi
7210787-1 Cable, E/P Regulator
7210787-3 Cable, E/P Regulator
7204797 Switch, Interlock, AB"ELF"
7200902-2 Main Board
7209880 Assy, Servo Power Supply
7206865 Servo AMP
7214000 PWA, Servo Power Control
7209610 Power Manager 10A
7201079 Drive Motors, XY
7210720 Computer, Laptop
7208938 PWA Accessories
7211935 PWB, Conveyor Control
7213997 Conveyor Motor
C.4 Illustrated Parts List
NOTE Parts listed in Figure C-1 to Figure C-8 are those in effect at the time of manual publication.
Refer to Asymtek’s Find-A-Part web page for the most current information.
http://webstore.asymtek.com/awweblive/apps/findapart_index.asp
