G-4 Glo ssary Pneumatic Devices : Ai r pressure actuated devices such as Stop Pi ns a nd B oard Pi ns. Port : A hardwa re i nterfa ce on a com puter t o whic h y ou can conn ect a device. Any machine conn ection that all…
Glossary G-3
Laser Fan Width Control System: Laser Fan Width
Control provides closed-loop monitoring of the
conformal coating process. The system automatically
verifies and adjusts the fan width prior to and/or after
the coating operation. Fan width programming is done
through the ECXP software.
Laser Pointer Programming Tool: Projects a red dot
onto the workpiece, which simulates the center point of
the dispensing module for faster identification of
program begin and end points.
LED: Light-Emitting-Diode. A semiconductor that
emits light. The materials used in the diode determine
the color of light. Functions as a system status indicator
and as an element in the Camera light source.
Levelers: Four adjustable pedestals (feet) on the bottom
of the coating system.
Light Beacon: A safety device with colored lights and
an audible alarm that is attached to the top of a coating
system. Colored lights and an audible alarm indicate
machine status.
Low Air Pressure Sensor: If the air pressure drops
below a set point, this sensor alerts the operator of
pressure drop conditions.
Low Fluid Scale: The Low Fluid Scale detects a low
fluid condition by weighing the fluid reservoir. If the
weight drops below a preset value, a sensor triggers the
Light Beacon display and the software issues a warning
message. The sensor can be set to a level that provides
ample time to refill the reservoir before reaching an out-
of-material condition. The Low Fluid Scale is used for
fluids where direct contact with the sensor is not
feasible.
Low Fluid Sensor: The Low Fluid Sensor triggers a
Light Beacon display and software warning message
when the level of coating material is low. The sensor
can be set to a level that provides ample time to refill the
reservoir before reaching an out-of-material condition.
The Low Fluid Sensor is located within the external
reservoir and is used for fluids that allow direct sensor
immersion.
Low Solvent Cup Sensor: The Low Solvent Cup
Sensor triggers a light beacon display and software
warning message when the level of solvent in the cup is
low. The software timer can be set to a level that
provides ample time to refill the cup before reaching an
out-of-solvent condition.
Main Air Inlet: The Main Air Inlet connects the
coating system to your facility air supply.
Main Power Inlet: The Main Power Inlet connects the
Main Power cable from the facility power source to the
coating system.
Maintenance: Planned or unplanned activities intended
to keep the coating system in good working order.
Material Change Over System: Allows you to switch
air and fluid lines between two reservoirs and the fluid
system without physically disconnecting fittings and
hoses.
Material Safety Data Sheet (MSDS): Information
sheet for the safe usage of a specific material. It is
provided by the material manufacturer and is usually
included in the fluid material packaging.
Moisture (RTV) Cure: Cures (hardens) coating
materials using ambient conditions or a humidity-
controlled environment.
Monofilament Mode: Conformal coating applied in a
looping pattern. Available with the SC-200 Slim Swirl
Applicator and Tri-Mode Swirl Box.
OEM: Original Equipment Manufacturer.
Operation: Functions, such as setting and manipulating
coating system controls, by which the operator causes
the equipment to perform its intended purpose.
Operator Interface: The machine/operator interface
that consists of Control Panels, Monitor, software, and
keyboard and mouse
Operator: A non-technical level position. The
production operator monitors and operates pre-
programmed coating systems during production runs
and performs minor routine maintenance.
Outputs: Electrical signals to control devices that must
turn ON and OFF on command.
Pattern Frame: The origin coordinates of patterns in
ECXP, other than the Main Pattern, are expressed as a
set of coordinates in the Product Frame. The pattern
origin coordinates are stored in the Pattern Edit Frame
when the pattern is created. See also Product Frame,
Base Frame, and Reference Frames.
PCB: Printed Circuit Board. The completed PWB with
electrical components installed. Also known as a Printed
Wiring Assembly (PWA).
Personal Protective Equipment (PPE): Clothing and
Equipment worn to reduce the risk of personal injury
from hazards associated with operation, maintenance,
and servicing of the coating system. This includes the
wearing of rubber gloves and safety glasses.
Pixels: Abbreviation for “Picture Element”. A pixel is a
single dot in a graphic image. The Computer Monitor
displays pictures by dividing the display screen into
thousands (or millions) of pixels, arranged in closely
spaced rows and columns. A pixel usually consists of
color and brightness information.
G-4 Glossary
Pneumatic Devices: Air pressure actuated devices such
as Stop Pins and Board Pins.
Port: A hardware interface on a computer to which you
can connect a device. Any machine connection that
allows for the exchange of electrical communication
signals. An opening in a mechanical device such as the
vacuum port in a contact heater or the conveyor port on
the Coating system.
Power Manager Module: The Power Manager Module
controls both AC and DC power supplied to all system
components.
Process Engineer: A technical level position. The
Process Engineer designs and develops processes for
automated electronic packaging using production line
equipment.
Product Frame: Product frames exist within the Base
Frame. ECXP uses fixture constraint coordinates, plus
the length and width of the product, to calculate the
coordinates of the Product Frame within the Base
Frame. The Product Frame origin is the calculated Main
Pattern Edit Frame. See also Base Frame, Pattern
Frame, and Reference Frames.
Production Shutdown: When all dispensing has been
stopped under non-emergency conditions such as the
end of a shift.
Psi: Pressure measured in Pounds Per per Square Inch
(lbs/in
2
). English unit of pressure measurement.
PWA: Printed Wiring Assembly. The completed PWB
with electrical components installed. Also known as a
Printed Circuit Board (PCB).
PWB: Printed Wiring Board. An insulating board
containing conductive tracks for electrical circuit
connections on which chips and other electronic
components are placed.
Reference Frames: All positioning in the workcell is
done with reference to sets of position coordinates,
called Reference Frames. In ECXP, three different sets
of Reference Frames are used: Base Frame, Product
Frame, and Pattern Frame.
Regulator: Device for controlling the amount of air
pressure supplied to a pneumatic system.
Reservoir Air Pressure Switch: Three-position switch
that toggles the air supplied to Reservoir A, Reservoir
B, or neither.
Robot: Dispensing Head.
Safe Z Height: This is the height below which the tool
tip cannot go when moving from one set of coordinates
to another during operation.
Safety Interlock System: An interlock sensor detects if
the dispensing area hood is open or closed. If the
dispensing area hood is opened when a program is
running, all dispensing motion stops to protect the
operator from injury. A second interlock sensor is
located behind the spill pan to ensure an appropriate
ventilation path when the drawer is pulled out for
maintenance.
SC-105HS High Speed Film Coater: Asymtek 5-axis
circulating fluid applicator, with a 0-360° rotate
mechanism plus tilt, which applies conformal coating in
a film rather than an atomized spray.
SC-204HS High Speed Non-Circulating Film Coater:
Asymtek 4-axis non-circulating fluid applicator, with a
0-90° rotate mechanism, that applies conformal coating
in a film rather than an atomized spray.
SC-205 Non-Circulating Film Coater: Asymtek 5-axis
non-circulating fluid applicator, with a 0-360° rotate
mechanism plus tilt that applies conformal coating in a
film rather than an atomized spray.
SC-300 Swirl Coat Applicator: The SC-300 Swirl
Coat applicator offers three modes of operation - bead,
monofilament and swirl. Ideal for conformal coating
applications, the SC-300 handles a wide range of
materials, varying in viscosity from 30 to 3500 mPa-sec
(30 to 3500 centipoise). The SC-300 is designed for use
with solvent-less coatings, supporting environmentally
responsible practices. A four-position tilt option is
available to allow coating access to vertical sides of
components.
SC-400 PreciseCoat Conformal Coating Jet: A non-
contact coating applicator ideal for applying conformal
coating materials to highly selective areas. This solution
is designed for coating small substrates or substrates
with high component density, and when there are tight
tolerances between coated and uncoated areas. The
SC-400 jet reaches locations not accessible by other
applicators, using a needle design with jetting action and
fast pulse-width modulated control.
SCFM: Standard Cubic Feet per Minute. A unit of flow
of a liquid or gas.
Select Cure UV-5 Cure Module: Asymtek's Select
Cure inline UV oven with modular design, ideal for
curing topside, bottom-side or both sides of PCBs in a
mid- to high-volume production environment. Coating
materials are cured using ultra-violet light.
Select Cure UV-6 Cure Module: Asymtek's Select
Cure inline UV oven with modular design, ideal for
topside curing in a mid- to high-volume production
environment. Coating materials are cured using ultra-
violet light.
SEMI: Semiconductor Equipment and Materials
International. An organization that defines protocols for
the semiconductor industry.
Glossary G-5
Service Shutdown: When all dispensing is stopped and
the coating system is made safe so that servicing can be
performed.
Service Technician: Trained personnel responsible for
performing advanced system servicing procedures.
SMEMA: Surface Mount Equipment Manufacturers
Association. Established protocol for signal
communication between two or more different systems.
Stop Pin (SL-940E): The Stop Pin is a pneumatic
device used to stop workpieces as they are conveyed
into the system.
SVGA: Super Video Graphics Array. A video card that
produces high-quality color images at high resolution.
TFT: Thin Film Transistor. The Monitor component
that provides color images for a liquid crystal display.
Tool Offset: The tool offset is the X, Y, and Z distance
from the robot's lower tooling pin to the tool tip (the end
of the nozzle). Robot position is calculated using the
coordinates of the tooling pin plus the offset.
Tool: A tool generally consists of a coating applicator
and nozzle. It may also be a teach camera, or a laser
pointer for programming.
Tooling Rails (SL-941E): The adjustable Tooling Rails
secure the workpiece for batch system operation.
Upstream/Downstream SMEMA Sensors: Mounted
on a bracket attached to the conveyor rail, upstream and
downstream SMEMA sensors allow you to manually
load and unload workpieces onto the conveyor in the
absence of upstream or downstream systems.
UV-Cure: Curing method that uses ultra-violet light to
cure (harden) coating materials.
V: Abbreviation for volt as in VAC (Volts Alternating
Current). See also AC, DC.
Valve: See Coating Applicators.
Viscosity: Viscosity is a measurement of the flow
properties of a fluid. The ability of a fluid to resist
deformation under stress. High viscosity fluids have a
high resistance to flow, and low viscosity fluids have a
low resistance.
Water Trap: Moisture from the outside air can
condense in the pneumatic system. The Water Trap
collects this condensed moisture. The Water Trap must
be emptied when it’s full.
Workcell: Dispensing area.
Workpiece: The board or substrate (PCB, PWA, etc.) or
a carrier (pallet, auer boat, lead frame, etc.) to be
dispensed upon.
X-Axis: Left to right movement of the Dispensing Head
in the dispensing area (Workcell).
X-Beam: The apparatus that spans the width of the
dispensing chamber. The Dispensing Head is mounted
to the X-Beam and slides along it in the X-Axis.
Includes mechanical pulleys for the X-Axis cables.
Y-Axis: Forward and backward movement of the
Dispensing Head in the dispensing area (Workcell).
Z-Axis: Up and down movement of the Dispensing
Head in the dispensing area (Workcell).
