Appendix C - Parts List C-14
C.4.8 Conveyor Components
Appendix C - Parts List C-15
C.4.8 Conveyor Components (Continued)
Item No. Part No. Description
1 7204379 REFLECTOR,LFWC,TEFLON
2 7213997 ASSY,STEP MOTOR
3 7204931 ASSY,BOARD PIN,30MM
4 199070 ASSY,SOLVENT CUP,SINGLE
5 7207848 BELT,TIMING,.08PITCH,114GROOVE
6 7204088 LASER,LFWC,TEFLON
7 198799 ASSY,STOP PIN,30 DEG
8 7210974 ASSY,BOARD SENSOR
9 7209444 TIMING BELT,3MM PITCH,600GRV
10 392643 TUBING, 3/4" ID POLYURETHANE
11 7216544 DRAIN CUP,LFWC
12 7200318 BAFFLE,DRAIN PAN,LFWC
13 193543 ASSY,IDLE SPROCKET,CHAIN CONV
14 7207835 CHAIN,#25,340LINK,85"LONG
15 193720 SPROCKET,DRIVE #25,14 TOOTH
Figure C-8 Illustrated Parts List (Conveyor Components)
