A ppendix C - Parts List C-8 C.4.5 Z- Head Components
Appendix C - Parts List C-7
C.4.4 Electronics Components (Continued)
Item No. Part No. Description
1 7215968 ASSY,VENT SWITCH,.15-55" W.C.
2 7206865 PWA,CM SERVO AMP
3 7211935 PWA,CONVEYOR CONTROL
4 7200148 POWSUP,UNIV VAC TO 24VDC 100W
5 7208938 PWA,ACCESSORIES,940
6 7200902-2 PWA,940 MAIN,PROGRAMMED
7 7216553 ASSY,E/P REGULATOR,130 PSI
8 7210787-1 CABLE,E/P REGULATOR
9 7210792 ASSY,VALVE,3 WAY W/FITTINGS
10 7214000 PWA,SERVO POWER CONTROL
11 43-3017-00 FITTING,MALE,3/8TUBE X1/8 NPT
12 40-2125 VALVE, 3 WAY, HIGH FLOW
13 40-2840 MUFFLER, 1/8 MPT
14 43-3021-20 FITTING, ELBOW, 3/8 TUBE OD
15 7201081 SPARE KIT,X/Y SERVO MOTOR X1K
16 7210782-1 CABLE,VALVE
17 7210783-1 CABLE,DISPENSE SOLENOIDS
18 7210785-1 CABLE,DISPENSE SENSORS
Figure C-4 Illustrated Parts List (Electronics Components)
Appendix C - Parts List C-8
C.4.5 Z-Head Components
Appendix C - Parts List C-9
C.4.5 Z-Head Components (Continued)
Item No. Part No. Description
1 7216276 BOARD PRESENCE SENSOR
2 198503 BELT,3MM PITCH,6WD,59 TOOTH
3 7209888 ASSY,940 Z-HEAD
4 198500 ROTARY ACTUATOR,0-180 DEG
5 7209606-2 CABLE,940 CAMERA CONTROL SGNLS
6 7209631 CABLE,HI FLEX CAT6 SHIELDED,7M
7 7209895 CAMERA,GIGA-E,NO S/W LICENSE
8 7212939 LENS EXTENSION,1.5MM,25MM ID
9 7218795 LENS,25MM F1.6"C"-MNT,LOCK
Figure C-5 Illustrated Parts List (Z-Head Components)
