Chapter 6: Operation
Contents
Quick Start: Running a Job. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Preparing to Run a Pre-programmed Job . . . . . . . . . . . . . . . . . . . . . . . .6-4
Power up the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Home Motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Setup the Bowl Feeder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Setup the Taper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Select Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Setup the Pick Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Setup Vision. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
Run the Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
6-2 TM-403 User’s Guide
Quick Start: Running a Job D292105.8b.fm
Quick Start: Running a Job
The following is an outline of the basic steps required to run a pre-programmed job. More
detailed instructions follow in the next section of this chapter.
Caution: Users should always wear protective eye wear when operat-
ing or maintaining the TM-402.
1. Power up.
• Power up the machine by turning on the Main Power Switch.
• Press the Reset button.
2. Home the motors.
• Open the Run Tab on the HMI and select Home Motors.
3. Setup Bowl Feeder.
• Ensure correct Linear Track is installed.
• Load components.
4. Setup Taper.
• Ensure sufficient carrier tape and cover tape are loaded to complete the job.
• Load an empty take-up reel.
• Run peel force test to verify seal.
5. Setup the Pick Head.
• Ensure the correct nozzle is installed for the part that will be picked.
• Observe the vacuum sensor, adjusting nozzle pressure as necessary.
• Adjust Blow-off Pressure as needed to achieve proper part placement.
• Close the enclosure doors.
6. Select Job.
• Open the Job Tab on the HMI. Select the desired job from the Job Library and
press Open to open the selected job in the Run Tab.
Quick
Start
D292105.8b.fm Quick Start: Running a Job
Chapter 6: Operation 6- 3
7. Setup Vision.
• Open the Taper Tab on the HMI and advance to the second screen.
• Ensure camera is ON. Configure inspection as needed.
Note: To configure vision inspection, see Chapter 4: Setup.
8. Run the Job.
• On the HMI, select the Run Tab then press Run.
• Load/unload parts and reels as needed.
Caution!
V-TEK® Incorporated takes no responsibility for the safety of TM-402 if it is
used for any purpose other than the intended purpose as specified in this
User’s Guide.
Quick
Start
