Appendix A: Sensors A-6

SMC ZSE30 Vacuum Sensor D291842.11.fm

D292105.12a.fm

TM-402 Suggested Spare Parts List

Part Number Description Qty

102534 Reset Switch Contact 1

102597 Digital Pressure Switch 1

105786 Take-up Motor 1

200401 Sealer Air Regulator 1

200636 Solenoid Air Valve 1

201026 Pick & Place Vacuum Air Filter 1

201207 Convum Vacuum Cup 1

201280 Nozzle Cup A3, 60 x 30 2

209250 Pick & Place Spring 1

201271 SPT Vacuum Cup 1

201297 Large Quad Vacuum Cup 1

201298 Medium Quad Vacuum Cup 1

201299 Small Quad Vacuum Cup 1

210019 Taper Timing belt 1

210109 Pick & Place Timing Belt 1

212001 Solenoid O-Rings 3

212008 Taper Idler O-Ring 2

212025 Nozzle O-Rings 2

244010 Taper Thermocouple 2

244012 Taper Heater 2

261122 Heat Shoe 1

266737 Taper Drive Sprocket 1

292464 Convum Nozzle Kit 1

292465 Quad Nozzle Kit 1

292467 SPT Nozzle Kit 1

290603 Taper Upper PSA Wheel Assembly 2

500440 Vision Sensor Amplifier 1

Spare Parts List TM-401 User’s Guide

D292105.12a.fm

Caution!

Only genuine spares should be used on the TM-402. Failure to

use genuine spare parts could render the machine unsafe and

void factory warranty.
