6-4 6 anaging the data 7 Make a backup cop y . 1. Press the [Copy] button. A confirmation dialog box appears. 2. Press the [Y es] button to make a copy. TIP If you press the [Move] button, the selected data stored in t…
6-3
6
anaging the data
5
Line up the cursor with the board data to be backed up.
You can select multiple board data by selecting them while holding down the [Ctrl] key or [Shift] key.
When you want to select all board data in the list, press the [All selected] button.
c
Selecting the board data
Select the board data from the list.
Copy direction
[Lane] button
64602-N3-00
6
Designate the copy destination.
Press the [Media] button on the left when copying from right to left, or press the [Media] button on the
right when copying from left to right. The contents of the USB memory device are displayed. (You can
delete unnecessary files with the [Delete] button.)
Copying from right to left
[Media] button [Copy] button [Lane] button
64603-N3-10
6-4
6
anaging the data
7
Make a backup copy.
1. Press the [Copy] button.
A confirmation dialog box appears.
2. Press the [Yes] button to make a copy.
TIP
If you press the [Move] button, the selected data stored in the machine is transferred to the USB memory device.
8
Rename the board data as needed.
To change the board data name so that you can easily identify it as backup data, press the [Rename]
button. When the keyboard dialog box appears, enter a new name and press the [OK] button.
Renaming the board data
Enter a new name for backup data
[Rename] button
[Lane] button
64604-N3-10
9
Press the [Close] button to close the Board Explorer.
6-5
6
anaging the data
1.2 Making a back of system data
The following sections explain how to make a backup of VGOS system data including machine data.
Usually, a backup copy of system should be stored on a USB memory or network drive.
c
c
c
n
NOTE
•Torestoresystemdata:
If for some reason the data in the flash memory disk is destroyed, insert the media (USB memory device) that contains
the system backup data after reinstalling the system and application software. Then press the [System Backup] button
on the Setup screen and then the [Restore] button in the "System backup" dialog box that appears.
1
Insert a USB memory device into the USB port.
The USB port is located behind the media access door on the front left of the machine.
2
Check the USB memory device connection.
The indicator on the lower left of the operation screen shows the connection status.
The connection is complete when the USB memory device icon appears red.
The connection is incomplete if the USB memory device icon is grayed out.
If so, retry to insert the USB memory again.
