6-14 6 anaging the data 3. Production histor y The YSP allows collecting, storing and displaying production histor y data such as various types of production information and errors that occurred during automatic operat…
6-13
6
anaging the data
5
Press the [New] button and designate the database number.
When the dialog box for entering a database number appears, enter the database number where you
want to store the data and press the [OK] button.
When you enter “0” or leave it blank, the data will be stored in the first free number.
Database number input dialog box
Enter the database number where data should be copied.
64606-N3-10
6
Check the database information.
Check the message in the dialog box that appears, and press the [OK] button.
The data including the comment is stored and you will return to the database list.
Database registration message
64607-N3-00
TIP
Repeat the above procedure when you want to copy other data into the database.
7
Press the [Close] button to close the database list.
6-14
6
anaging the data
3. Production history
The YSP allows collecting, storing and displaying production history data such as various types of production
information and errors that occurred during automatic operation. This useful function allows you to evaluate
and improve daily operation conditions and also supports an automatic history data collection system using
an intra-network.
To check the production history data, press the [MIS] button on the main menu button area. Different types of
production history data are displayed by selecting the [Error Log], [Board Log] and [Program Log] tabs.
3.1 MIS: Error Log
Selecting the [Error Log] tab shows a list of errors that occurred in this machine, along with error descriptions
and operator names. One error or one operator is listed in one data row. Up to 1000 rows can be listed.
[MIS]-[Error Log] tab
[MIS] button
64608-N3-00
Each parameter item shows the following information.
Event Date Date and time when an error occurred.
Program Name Name of program being selected when an error occurred.
Program ID Comment of program being selected when an error occurred.
Event Number
Error code and number. The error code "Es" means a system error, and "Ea"
means an error relating to board data or operation.
Contents Description of error.
Details Detailed description of error such as location where error occurred.
Operator Name of operator who was operating machine when an error occurred.
6-15
6
anaging the data
The buttons at the lower right of the screen have the following functions.
[Save Log] button
Saves the production history data displayed on the screen.
[Clear] button
Clears all the production history data displayed on the screen.
[Option] button
Pressing this button opens the dialog box to show or hide each item of the production history data. Place a checkmark on
the item you want to display on the screen.
Dialog box for selecting display items
64609-N3-00
