YSP20_Users_E.pdf - 第68页

2-7 2  asic operations n Air-conditioner related errors Code Error name and description Ea8086 AIR-CONDITIONER TEMPERA TURE INTERLOCK State T emperature in the machine is not suitable for production. Y ou cannot run the…

100%1 / 280
2-6
2
asic operations
Code Error name and description
Ea8823
BOARD TRANSFER TIMEOUT
State Failed to transfer a board from the exit to the next machine.
Cause Board can stay between the lower conveyor and the entrance of the next machine.
Action Please remove the board.
Ea8849
Unknown board is detected at the wait position sensor
State Unknown board is detected at the wait position sensor.
Cause Unknown board is detected at the wait position sensor.
Action
1. If you supply the board to print now, please push [Unit] - [Conveyor] - [Convey In].
2. If you supply the printed board, please push [Setup] - [Setup] - [Print Board Convey Out] after remove the
board.
n
Mark related errors
Code Error name and description
Ea0256
Base-MACS Mark Detection Error
State Failed to detect Base-MACS mark.
Cause Check Base-MACS marker condition, and clean up the marker surface.
Action
Check Base-MACS marker condition, and clean up the marker surface.
To invalidate Base-MACS Function, please change the following item. [Machine Data]-[Machine Information]-
[Installation Setting]-[Base MACS]-[Not Use]
n
Cleaner unit related errors
Code Error name and description
Ea8095
CLEANING SOLVENT OUTPUT ERROR
State
Something is wrong in the output of the cleaning solvent.
Please release the EMERGENCY STOP,press [Fuel Pump] on [Unit/Cleaner] screen, and confirm whether the
cleaning solvent is correctly output.
When the cleaning solvent is not correctly output, the following causes are thought.
Cause
• Breakdown of relay of solvent pump.
• Abnormality of conveyer I/O board.
• Disconnection of I/O communication line.
Action
• Exchange of relay of solvent pump.
• Exchange of conveyer I/O boards.
• Please confirm disconnection of I/O harness,coming off of connector cable,and loosening of earth cable.
Ea8280
GAUZE ROLLING FINISHED
State All gauze has been rolled up.
Cause
Action Please exchange gauze roll for a new one.
Ea8288
CLEANER VACUUM UP CHECK ERROR
State The vacuum of the cleaner was not up when the cleaner head goes up.
Cause
1. The cleaner hose has damage.
2. The cleaner filter is choked up.
3. The exhaust valve is broken.
4. The blower motor is broken.
Action
Ea8289
CLEANER VACUUM DOWN CHECK ERROR
State The vacuum of the cleaner was not down when the cleaner head goes down.
Cause 1. The exhaust valve is broken.
Action
2-7
2
asic operations
n
Air-conditioner related errors
Code Error name and description
Ea8086
AIR-CONDITIONER TEMPERATURE INTERLOCK
State
Temperature in the machine is not suitable for production.
You cannot run the machine under this condition.
Cause
Please check Air-Conditioner.
1. Power supply off of Air-Conditioner
2. Air-Conditioner is not effective.
Action
Ea8087
AIR-CONDITIONER WATER FULL
State The water tank of Air-Conditioner is full.
Cause
Action
Ea8094
AIR-CONDITIONER INTERLOCK
State The Air-conditioner doesn't work normally.
Cause
Please check Air-Conditioner.
1. The Air-Conditioner broke down.
2. Ten minutes passed after the water tank of Air-Conditioner is full.
Action
n
Data check errors
Code Error name and description
Ea0452
DATA CHECK ERROR
State Current Board data has some data error.
Cause Current Board data has some data error.
Action Please read same Board data, and correct wrong data.
Ea8507
DATA CHECK ERROR
State Squeegee speed is out of range.
Cause Squeegee speed is out of range.
Action
Please specify correct speed as follows
• Double Squeegee : 1 to 200[mm/sec]
• Enclosed Head : 1 to 100[mm/sec]
Ea8508
DATA CHECK ERROR
State Print pressure is out of range.
Cause Print pressure is out of range.
Action Please specify correct pressure from 0.01 to 200[N].
Ea8513
DATA CHECK ERROR
State Detach speed is out of range. (0.1 to 20.0mm/sec).
Cause Detach speed is out of range. (0.1 to 20.0mm/sec).
Action
Ea8537
DATA CHECK ERROR
State Illegal mask size is specified.
Cause The size is not available in this machine.
Action
2-8
2
asic operations
Code Error name and description
Ea8548
PLEASE CHECK FOR ANY ILLEGAL RUNNING CONDITION
State
Operating condition settings are not suitable for production.
Check followings. If all OK, please continue.
Cause Operating condition settings are not suitable for production.
Action
Alignment should be [UseAlign].
PrintFeedback should be [Use].
Board Inspection JudgeMode should be [Normal Judge] or [Normal Judge & Exit Judge].
Ea8599
DATA CHECK ERROR
State
In 'Controlled in the Board' cleaning, each auto cleaning interval and manual cleaning interval
must satisfy
following magnitude relation.
Cause
In 'Controlled in the Board' cleaning, each auto cleaning interval and manual cleaning interval
must satisfy
following magnitude relation.
Action
Dry Auto Interval
< Wet Auto Interval
< 'Controlled in the Board 1' Detail Auto Interval
< 'Controlled in the Board 2' Detail Auto Interval
< 'Controlled in the Board 3' Detail Auto Interval
< 'Controlled in the Board 4' Detail Auto Interval
< Manual Interval
Ea8812
DATA CHECK ERROR
State The set board size Y is over the maximum board size Y of the mask.
Cause The set board size Y is over the maximum board size Y of the mask.
Action Please change the correct board size Y or set the correct size of the mask.
Ea8815
DATA CHECK ERROR
State
Although the board may be carried out to lane 2, the set board size Y is over the maximum board size Y that
can be carried out to lane 2.
Cause The size of boards to be unloaded to Lane 2 exceeds the maximum board size that can be transported.
Action Please change the correct board size Y or set the "Lane 1" to the "Carry out Lane Setting".
