YSP20

Maintenance Manual

General Contents

Introduction

1. About this manual i

2. Maintenance list ii

Chapter 1 Maintenance

1. Maintaining machine performance 1-1

1.1 Essential conditions and working environment 1-1

1.2 Importance of periodic inspections and cleaning 1-2

2. Preparing for maintenance tasks 1-3

2.1 Maintenance tools 1-3

2.1.1 Cleaning tools 1-3

2.1.2 Lubricating tools and grease 1-3

2.2 Required tools 1-4

Chapter 2 Inspection and maintenance

Before beginning work 2-1

1. Daily maintenance items 2-2

1.1 Daily inspection 2-2

1.2. Cleaning the camera protective glass 2-3

2. Periodic maintenance items 2-4

2.1 Periodic inspection (Weekly/Monthly) 2-4

2.1.1 Parts to be replaced during periodic replacement 2-4

2.1.2 List of periodic inspection checkpoints 2-4

2.2 Parts recommended for periodic replacement 2-6

2.3 Adjusting the conveyor belt tension 2-7

2.4 Inspecting and cleaning the air/mist filters 2-8

3. Replacing the consumable parts 2-10

3.1 Replacing the squeegee unit 2-10

3.2 Replacing the squeegee scraper 2-11

3.2.1 Metal squeegee scraper 2-11

3.2.2 Urethane squeegee scraper 2-12

3.3 Suction-blower unit 2-14

3.3.1 Cleaning and replacing the filter 2-14

3.3.2 Replacing the blower hose 2-15

3.4 Cleaning/replacing filter for mask vacuum chuck 2-17

3.5 Replacing the conveyor belt 2-18

EMN3192110

Chapter 3 Lubrication points

1. List of lubrication locations 3-1

1.1 Applicable grease 3-1

1.2 Grease gun 3-1

2. List of lubrication locations 3-2

2.1 X- and Y-axis 3-2

2.1.1 X1-axis and X2-axis 3-2

2.1.2 Y1-axis and Y2-axis 3-3

2.2 Printing head 3-4

2.2.1 SY-axis 3-4

2.2.2 SZ-axis 3-4

2.3 Mask table ASSY 3-5

2.3.1 MY-axis 3-5

2.3.2 MZ-axis 3-5

2.4 Conveyor unit 3-6

2.4.1 PU1-axis and PU2-axis 3-6

2.4.2 W1-axis and W2-axis (Conveyor auto width adjustment) 3-7

2.5 Suction-blower unit 3-8

2.5.1 Blower hose guide 3-8

Appendix

1. Specifications A-1

1.1 Air regulator unit A-1

1.2 Power connection terminals A-2

1.3 Connection between machines A-3

1.3.1 PREVIOUS INTERFACE connector A-4

1.3.2 NEXT INTERFACE connector A-6
