xxiii Safety instructions 3.4 Label positions T he following warning/caution labels are attached to the Y AMAHA products to ensure safe and correct use. Check that the information on eac h label is clearly legible and co…
xxii
Safety instructions
Potential
hazard
Could cause machine damage (collisions with the head, etc.).
To avoid
hazard
Verify that no objects have been placed on the batch change carrier's (for YSM40) top cover.
Applicable
machines
Feeder exchange carriage (YSM40)
Case
Setup
Potential
hazard
The top tape could make contact with the head, possibly causing machine damage.
To avoid
hazard
When a feeder is improperly extracted from its set position, be sure that the feeder has been
completely extracted before reinserting it into its set position.
Applicable
machines
YSM40
Case
Setup
xxiii
Safety instructions
3.4 Label positions
The following warning/caution labels are attached to the YAMAHA products to ensure safe and correct use.
Check that the information on each label is clearly legible and comply with the instructions.
n
NOTE
Basically, labels are attached to the positions shown below, although they may differ slightly depending on the
machine model.
n
Label positions
Warning/caution labels
YSP20 front view (right-to-left flow)
1
1
1
4
4
7
5
2
N
Labels
3
6 (Two each on left and right sides)
3
3
2
2
1
2
2
5
7
2
6
93201-N3-00
xxiv
Safety instructions
Warning/caution labels
YSP20 rear view (right-to-left flow)
1
2
3
2
1
2
2
2
3
1
4
N
Labels
5
7
7
3 2
6
6 (Two each on left and right sides)
93202-N3-00
