2.1 "Product" Tab
*3 Maint. Stop Total Count
This indicates the number of times the machine was stopped for
maintenance operations (described below in *4 through *7).
The indicated value is the total of *4 through *7.
*4 Hand Cleaning Stop Count
This indicates the number of times the machine was stopped for
manual cleaning operations.
*5 Solvent Shortage Stop Count
This indicates the total number of times the machine was
stopped because it was detected that only a little amount of
cleaning solvent remained.
*6 Paper Shortage Stop Count
This indicates the total number of times the machine was
stopped because it was detected that the machine became
empty of cleaning paper.
*7 Paste Shortage Stop Count
This indicates the total number of times the machine was
stopped because the number of P.C.B.’s (Paste Empty Stop
(PCB)) reached the specified value.
When the paste remainder detection sensor (option) is
used, it detects that paste is consumed up and the
number of times by which the machine has stopped is
also added.
Tg0699-PM-D2
0207-001 Chapter 1 3-8
2.2 "Time Data" Tab
*1
*2
*3
*4
*5
*6
*7
*8
*9
*10
*11
*12
*13
*14
*15
*16
*17
2.2 "Time Data" Tab
Displayed is the data that represents the cumulative periods of run-
ning time for each operation mode.
••
••
• Sheet Layout
When the "Time Data" tab is pressed in the "MANAGE. DATA 1"
window (submenu), the following tab sheet appears.
Fig. 3C5 "Time Data" Tab Sheet
••
••
• Sheet Composition
*1 Ratio Chart of Operation Time
Each time ratio based on "Power ON Time" (described below in
*2) is classified by colors and charted by columns. The colors in
the chart correspond to those indicated before each name.
Each time ratio is updated every 5 seconds.
*2 Power ON Time
This indicates the cumulative period of time ("*3 AUTO OPN.
TIME" + "*10 Stop Time") during which the control power was
ON.
*3 AUTO OPN. TIME
This indicates the cumulative period of time ("*4 Printing Time" +
"*5 PCB Trans. Time" + "*6 PCB Wait Time" + "*9 Print. Test
Time") during which the object P.C.B.’s were produced.
Tg0699-PM-D2
*4 Printing Time
This indicates the cumulative period of time during which printing
operations were actually performed (from the start to the end).
The cumulative period of time does not include the
periods of time during which the machine is in the
"STOP" or the "PAUSE" mode, the semi-auto operation
is performed, or P.C.B.’s are transferred.
*5 PCB Trans. Time
This indicates the cumulative period of time during which the
P.C.B. transfer motors for the R and L conveyors were activated.
The cumulative period of time does not include the
printing time.
*6 PCB Wait Time
This indicates the cumulative period of time ("*7 Inp. Mach.
Wait" + "*8 Out. Mach. Wait") during which the main machine
was waiting for the input and output machines to transfer or
discharge a P.C.B.
*7 Inp. Mach. Wait
This indicates the cumulative period of time during which the
main machine was waiting for the input machine to transfer a
P.C.B.
*8 Out. Mach. Wait
This indicates the cumulative period of time during which the
main machine was waiting for the output machine to discharge a
P.C.B.
*9 Prin. Test Time
Displayed is the time required to inspect the printing condition of
the P.C.B. This printing condition inspection function is optional.
When the machine is not provided with this function, "0" (zero)
will be set in the "Prin. Test Time" text box.
*10 Stop Time
This indicates the cumulative period of time ("*11 Maint. Stop
Time" + "*12 Error Stop Time" + "*15 Others") during which the
machine was stopped.
