Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-99
Table 4B97
Error ID Item Description
1906038
Screen Recognition
Unavailable fiducial mark polality was set.
Camera
1906040
Screen Recognition
Unavailable fiducial mark area was set.
Camera
1906043
Screen Recognition
Recognition system error.
Camera
1906056
Screen Recognition
Recog. transaction time over.
Camera
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-100
Table 4B98
Error ID Item Description
2001000 Cleaning Interlock P.E.C. Recog-Y Axis is not at safety area.
(Cause 1) The cleaning nozzle was moved up when the P.E.C. recognition Y axis was
not located at its front escape position (origin position).
(during the manual operation)
(Cause 2) The P.E.C. recognition Y-axis near origin sensor (BPH331) is defective.
(Cause 3) The operation timing is shifted from the normal one.
(Remedy 1) Zero the P.E.C. recognition Y axis and re-start the operation.
(Remedy 2) Zero the P.E.C. recognition Y axis.
When the P.E.C. recognition Y axis cannot be zeroed, it is required to
replace the sensor with a new one. Contact our service personnel for
details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, re-start the operation.
When the same error still occurs, contact our service personnel for de-
tails.
Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-101
Table 4B99
