Tg0699-PM-D2 2.3 Error IDs and Remedial Procedures 0207-001 Chapter 2 2-73 T able 4B71
Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-72
Table 4B70
Error ID Item Description
1409000 Printing Pressure Printing pressure exceeded upper range. (Peak)
Setting
(Cause 1) The printing pressure was not constant temporarily.
(Cause 2) The output value of the load cell is abnormal.
(Remedy 1) Check for any foreign substances on the production P.C.B. and the screen.
(Remedy 2) Check for any foreign substances near the load cell.
When the same error still occurs, contact our service personnel for de-
tails.
1410000 Squeegee Up/Down Squeegee up/down cylinder, Squge.Y axis was not at
Interlock safety area.
(Cause 1) The range of the squeegee movement has exceeded the limited one.
(Remedy 1) Check if the parameters in the "Origin" and "Depth" text boxes of "Print
Area" in the P.C.B. Data" tab sheet ("Pattern Program" window) and the
parameters in the "Paste Size" and "Print Margin" group boxes in the
"Printing Condition" tab sheet ("OPN. MODE" window) are too large or
not.
1412000 Squeegee Up/Down Squeegee up/down cylinder, PCB was not checked.
Interlock
(Cause 1) The squeegee was moved down when a P.C.B. was not clamped on the
table. (during the manual operation)
(Remedy 1) Clamp the P.C.B. in the table section and move up the table. After that,
re-start the operation.
Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-73
Table 4B71
Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-74
Table 4B72
Error ID Item Description
1501000 Load Power [Emergency] button pressed.
Shut-Off
(Cause 1) An [EMERGENCY STOP] button was pressed.
(Remedy 1) Unlock the [EMERGENCY STOP] button and hold down the [POWER
ON] button for more than 3 seconds. After that, press the [RESET] button
in the "ERROR" window.
1502000 Load Power The air pressure is too low.
Shut-Off
(Cause 1) The main air pressure had dropped below 0.4 MPa (the set value of the
pressure switch).
(Remedy 1) Adjust the pressure to the correct one.
1503000 Load Power The safety door is open.
Shut-Off
(Cause 1) The safety door was opened.
(Remedy 1) Close the safety door and hold down the [POWER ON] button for more
than 3 seconds. After that, press the [RESET] button on the touch screen.
Power up the machine again and re-start the operation.
1504000 Load Power Detected circuit breaker off.
Shut-Off
(Cause 1) The circuit breaker of Q100, Q202, Q203 or Q204 is turned OFF.
(Remedy 1) Contact our service personnel for details.
1505000 Load Power Detected all load power monitor off.
Shut-Off
(Cause 1) The load power supply monitor (K021) is turned OFF.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
If possible, check how the fuse (F001), K14, K15, K16, KM100, and KM200
are working.
