Tg0699-PM-D2 7. Maintenance (Every 3 Months after Initial Month) NM1: MOL YNOC GREASE AP 1 7. Maintenance (Every 3 Months after Initial Month) Fig. 5A34 T able Section Outer Circumference of θ -Axis Movable Bearing Apply…
Tg0699-PM-D2
Spline Shaft for Width
Adjustment
Clean the shaft with an
oiled rag.
Note : Remove waste thread
if any.
Cleaning
Ball Screw for Width
Adjustment
Cleaning
Guide Bushing for Width
Adjustment
Cleaning
Clean the screw with an
oiled rag.
Note : Remove waste thread
if any.
Clean the bushing with an
oiled rag.
Note : Remove waste thread
if any.
Spline Shaft for Width
Adjustment
Clean the shaft with an
oiled rag.
Note : Remove waste thread
if any.
Cleaning
Ball Screw for Width
Adjustment
Cleaning
Guide Bushing for Width
Adjustment
Cleaning
Clean the screw with an
oiled rag.
Note : Remove waste thread
if any.
Clean the bushing with an
oiled rag.
Note : Remove waste thread
if any.
6. Monthly Maintenance
Fig. 5A32 L Conveyor Section
Fig. 5A33 R Conveyor Section
0207-001 Chapter 3 1-24
Tg0699-PM-D2
7. Maintenance (Every 3 Months after Initial Month)
NM1: MOLYNOC GREASE AP 1
7. Maintenance (Every 3 Months after Initial Month)
Fig. 5A34 Table Section
Outer Circumference of
θ-Axis Movable Bearing
Apply grease with a brush or
a spatula.
Lubrication
0509-002 Chapter 3 1-25
Table 5A7
Maintenance Spots
Description
Grease
Cleaning
Check
Tools,
Nozzles,
etc.
Table Section
Outer Circumference
5A34 Lubrication NM1 Brush,
of θ-Axis Movable Spatula
Bearing
Block Name Detailed Name
Fig.
No.
Tg0699-PM-D2
Table 5A8
Maintenance Spots
Description
Grease
Cleaning
Check
Tools,
Nozzles,
etc.
Table Section X-Axis Ball Screw 5A35 Lubrication DE1 Brush,
Spatula
X-Axis Linear Guide 5A36 Lubrication DE1 Grease Gun,
Brush
Z-Axis Ball Screw 5A37 Lubrication DE1 Brush,
Spatula
Z-Axis Guide 5A37 Lubrication DE1 Brush,
Bushing Spatula
θ-Axis Ball Screw 5A38 Lubrication DE1 Brush,
Spatula
θ-Axis Linear 5A38 Lubrication DE1 Brush,
Guide Spatula
P.C.B. Chuck Ball Screw for Chute 5A39 Lubrication DE1 Brush,
Section Width Adjustment Spatula
Linear Guide for 5A39 Lubrication DE1 Brush,
Chute Width Spatula
Adjustment
Ball Screw for Chute 5A41 Lubrication DE1 Brush,
Width Adjustment Spatula
Linear Guide for 5A41 Lubrication DE1 Brush,
Chute Width Spatula
Adjustment
Backup Table Z-Axis 5A40 Lubrication DE1 Brush,
Guide Bushing Spatula
Backup Table Z-Axis 5A39 Lubrication DE1 Brush,
Ball Screw Spatula
Linear Guide for 5A42 Lubrication DE1 Brush,
P.C.B. Clamping Spatula
P.E.C. Recogni- P.C.B. Stopper 5A43 Lubrication DE1 Brush
tion Section Guide Bushing
X-Axis Linear Guide 5A43 Lubrication DE1 Brush,
Spatula
Y-Axis Ball Screw 5A44 Lubrication DE1 Brush,
Spatula
Y-Axis Linear Guide 5A44 Lubrication DE1 Brush
X-Axis Ball Screw 5A44 Lubrication DE1 Brush,
Spatula
