Tg0699-PM-D2
2.1 Navigations in Window
0207-001 Chapter 1 2-39
2.1.3 Saving a Pattern Program
This session describes how to save a newly created or an edited
pattern program.
• Operation Procedure
(1) Click "File" on the menu bar. The pull-down menu opens. Select
"Save" or "Save As..." from the pull-down menu.
Save : Select this to replace the source pattern program
with the edited one.
Save As... : Select this to save a newly created pattern pro-
gram or an edited pattern program as another one
(different from the source program).
(2) When you select "Save", the active pattern program is saved
with the same name (model name) as that of the source pattern
pro-gram. The source pattern program is replaced with the
active one.
When the program is saved, a "File save complete" message
ap-pears on the status bar of the "Pattern Program" window.
(3) When you select "Save As...", the "Virtual Keyboard" (Fig. 3B79)
and the following "Save" window open.
Fig. 3B84 "Save" Window
(4) Enter a comment (up to 16 characters) on the selected program
in the "Comment 1" and "Comment 2" text boxes and the pro-
gram name (up to 24 characters) in the "Program Name" text
box, using the "Virtual Keyboard" .
Tg0699-PM-D2
2.1 Navigations in Window
(5) Press the [OK] button in the "Save" window.
The pattern program displayed in the edit sheet is saved with
entered file (program) name.
(a) When a long string of characters is entered in the
"Program Name" text box, the name may not be fit
inside the text box, making the last few characters
invisible. It is advisable that up to 24 characters
should be used.
(b) The following characters can not be used as a
pattern program name.
* (asterisk), ? (question mark), : (colon),
" (double quotation), / (slash), | (vertical line),
< (smaller than), > (larger than), (comma),
. (period)
(c) The ", "(comma) cannot be used as a comment.
0207-001 Chapter 1 2-40
Tg0699-PM-D2
0207-001 Chapter 1 2-41
2.1 Navigations in Window
2.1.4 FD Backup/Restore
The pattern programs stored on the built-in HDD (hard disk drive) of
this machine can be saved on FDs (floppy disks) or the data on an
FD (floppy disk) can be restored onto the hard disk of the machine.
Select the icon on the toolbar of the "Pattern Program" edit
window or "Tool" on the menu bar. When you push "Tool" on the
menu bar, the pull-down menu opens. Select "FD Backup..." from the
pull-down menu.
The following "FD Backup/Restore" window opens.
Fig. 3B85 "FD Backup/Restore" Window
Working with "FD Backup/Restore" Window
• The left pane displays a list of the pattern programs saved on the
hard disk of the machine.
• The right pane displays a list of the pattern programs saved on an
FD (floppy disk) inserted into the FDD (floppy disk drive) of the
machine.
• When you press the [Select All->>] button, all pattern programs on
the FD (floppy disk) are selected.
• When you select a pattern program(s) from the left pane and press
the [Current ->> FD] button, the selected pattern program(s) is
saved on the FD (floppy disk).
