Tg0699-PM-D2
0207-001 Chapter 1 4-7
2.1 "Password" Tab
*2
*1
*3
*4
2.1 "Password" Tab
Passwords can be set as a means of security for different operators
of the machine. Depending on the set passwords, different authoriza-
tion (permission and privilege) is given to each operator such that
only approved operators can gain access to certain functions of the
machine.
The "Password" tab sheet is composed of two tab sheets - "Pass-
word In" and "Available Area".
2.1.1 "Password In" Tab
••
••
• Sheet Layout
When the [Password] tab is pressed in the "MAC. SET-UP" win-
dow (submenu), the following tab sheet appears.
Fig. 3D6 "Password" Tab Sheet
Tg0699-PM-D2
0207-001 Chapter 1 4-8
2.1 "Password" Tab
••
••
• Sheet Composition
*1 Security Level Selection Buttons
These buttons can be used to allocate the security levels to the
operators of the machine.
Supervisor Person who has managerial responsibility for the
machine
Operator #1 Person who is given access to a wide range of
available areas
Operator #2 Person who is given access to a certain range of
available areas
When a button is pressed, the background color turns into the
frame one (red, green, or yellow).
(a) It is advisable that a password be set as a means of
security for the supervisor.
Otherwise, a third party has authorization to operate the
machine and an accident or a breakdown may result.
(b) Be sure to make the "LOG IN" window appear after the
end of machine operations.
Otherwise, an operator with less authorization or a third
party can operate the machine and an accident or a
breakdown may result.
(c) When the supervisor has forgotten his/her password,
the functions on the "Password In" and "Available Area"
tab sheets become unavailable.
Keep the password confidential.
*2 "Password In" and "Check Password In" Text Boxes
*3 [SET] Button
The entered password is stored in memory of the machine.
*4 [Password Clear] Button
The entered password can be cleared.
Tg0699-PM-D2
0207-001 Chapter 1 4-9
2.1 "Password" Tab
••
••
• Operation Procedure
(1) Make the alphabet keyboard or the ten-key window appear.
(2) Enter the password in the *2 "Password In" text box, using the
"virtual keyboard" window or the "ten-key" window and then
press the *3 [SET] button. Enter alphanumeric characters (up
to 8 characters) as a password.
(3) Enter the same password in the "Check Password In" text box
and press the *3 [SET] button.
When the first and second passwords are not identical, the
"LOG IN" window appears.
The "ENTER PASSWORD" dialog box pops out. Enter the
correct password again.
(a) When a wrong password is entered, press the *4
[Password Clear] button and enter the correct one
from the beginning. Or, use the [BS] (backspace) key,
the [←] key, or the [→] key to correct the entry.
(b) When no password is entered and the *3 [SET]
button is pressed or a button or a tab is selected to
open another window or sheet, another window or
sheet does not open because the system recognizes
that no password is entered. The "Password" tab
sheet remains active.
