Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-86
Table 4B84
Error ID Item Description
1804038 P.E.C. Recognition Unavailable fiducial mark polality was set.
Test
1804040 P.E.C. Recognition Unavailable fiducial mark area was set.
Test
1804043 P.E.C. Recognition Recognition system error.
Test
1804056 P.E.C. Recognition Recog. transaction time over.
Test
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-87
Table 4B85
Error ID Item Description
1806000 P.E.C. Recognition
Camera
1806001 P.E.C. Recognition [Camera ID] exceeds the range of setting.
Camera
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If the machine is not reset to its normal condition, shut down the power of
the machine once and power up the machine again. After that, re-start
the operation.
When the same error still occurs, contact our service personnel for de-
tails.
1806003 P.E.C. Recognition [Camera Gain] exceeds the range of setting.
Camera
1806004 P.E.C. Recognition [Camera Level] exceeds the range of setting.
Camera
1806011 P.E.C. Recognition [Mark Size D1] exceeds the range of setting.
Camera
1806012 P.E.C. Recognition [Mark Size D2] exceeds the range of setting.
Camera
1806014 P.E.C. Recognition [Mark Judge Level] exceeds the range of setting.
Camera
(Cause 1) The data has exceeded the allowable range.
(Remedy 1) Set correct parameters.
1806029 P.E.C. Recognition Image around fiducial mark was unstable.
Camera
1806030 P.E.C. Recognition Error of mark figure similitude was extensive.
Camera
1806031 P.E.C. Recognition Error of mark similitude or mark size was extensive.
Camera
1806032 P.E.C. Recognition Specified mark was not found in window of recog.monitor.
Camera
(Cause 1) The fiducial marks do not conform to the coordinates X and Y of the fiducial
marks or the recognition mark data in the pattern program.
(Remedy 1) Refer to Error ID 1801032 for details.
Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-88
Table 4B86
Error ID Item Description
1806038 P.E.C. Recognition Unavailable fiducial mark polality was set.
Camera
1806040 P.E.C. Recognition Unavailable fiducial mark area was set.
Camera
1806043 P.E.C. Recognition Recognition system error.
Camera
1806056 P.E.C. Recognition Recog. transaction time over.
Camera
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
