Tg0699-PM-D2
Layout of Console Section
0207-001-(M782YRH--0001) Chapter 3 3-36
Layout of Console Section
Tg0699-PM-D2
Layout of Input/Output Machines Interface Section
0207-001-(M782YRJ--0001) Chapter 3 3-37
Layout of Input/Output Machines Interface Section
Interface P.C.B.
Mount Base (attachment : Truss-head Screws M4L6)
Install with key set to downward.
Tg0699-PM-D2
3. Location of Sensors and Loads
0207-001-(M782YHL--0001) Chapter 3 3-38
3. Location of Sensors and Loads
3.1 Location of Sensors and Loads in Conveyor
Section
(1) L Conveyor Section
Direction of P.C.B. Transfer
Origin
Conveyor Motor
Conveyor Width Axis
Pulse Motor
P.C.B. Detection
P.C.B. Stoppe
r
Output Side
Connected to
the Frame
P.C.B. Transfer Check
