Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-93
Table 4B91
Error ID Item Description
1901038 Screen Unavailable fiducial mark polality was set.
Fiducial Mark #1
1901040 Screen Unavailable fiducial mark area was set.
Fiducial Mark #1
1901043 Screen Recognition system error.
Fiducial Mark #1
1901056 Screen Recog. transaction time over.
Fiducial Mark #1
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-94
Table 4B92
Error ID Item Description
1902000 Screen
Fiducial Mark #2
1902001 Screen [Camera ID] exceeds the range of setting.
Fiducial Mark #2
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If the machine is not reset to its normal condition, shut down the power of
the machine once and power up the machine again. After that, re-start
the operation.
When the same error still occurs, contact our service personnel for de-
tails.
1902003 Screen [Camera Gain] exceeds the range of setting.
Fiducial Mark #2
1902004 Screen [Camera Level] exceeds the range of setting.
Fiducial Mark #2
1902011 Screen [Mark Size D1] exceeds the range of setting.
Fiducial Mark #2
1902012 Screen [Mark Size D2] exceeds the range of setting.
Fiducial Mark #2
1902014 Screen [Mark Judge Level] exceeds the range of setting.
Fiducial Mark #2
(Cause 1) The data has exceeded the allowable range.
(Remedy 1) Set correct parameters.
1902029 Screen Image around fiducial mark was unstable.
Fiducial Mark #2
1902030 Screen Error of mark figure similitude was extensive.
Fiducial Mark #2
1902031 Screen Error of mark similitude or mark size was extensive.
Fiducial Mark #2
1902032 Screen Specified mark was not found in window of recog.monitor.
Fiducial Mark #2
(Cause 1) The fiducial marks do not conform to the coordinates X and Y of the fiducial
marks or the recognition mark data in the pattern program.
(Remedy 1) Refer to Error ID 1901032 for details.
Tg0699-PM-D2
2.3 Error IDs and Remedial Procedures
0207-001 Chapter 2 2-95
Table 4B93
Error ID Item Description
1902038 Screen Unavailable fiducial mark polality was set.
Fiducial Mark #2
1902040 Screen Unavailable fiducial mark area was set.
Fiducial Mark #2
1902043 Screen Recognition system error.
Fiducial Mark #2
1902056 Screen Recog. transaction time over.
Fiducial Mark #2
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
