CELL STAT : Press to change the cell status. INITIALIZE : Press to clear the program changeover memory. CODE READ : Press to carry out the code reader test. ADJ. TEST : Press to carry out test of conveyor width adjustmen…

100%1 / 261
Press this function key to change the mode of communication with the MCS.
Local : Only status data, Proper data and programs can be transmitted from
the MCS.
Off Line : Production data can be transmitted from the machine to MCS.
Chapter 3 Description of Commands
Part 3
3 - 35
Version 2.0 GL-541E Operation
MCS Changing the Communication Mode 515-100
FUJI
Off line
Page 515-1
Command path:
GL_541E Prod 0000 Sche 00000
MCS
[SET] - [STATUS] - [LINE] - [MCS]
• Explanation To page
CELL STAT : Press to change the cell status.
INITIALIZE : Press to clear the program changeover memory.
CODE READ : Press to carry out the code reader test.
ADJ. TEST : Press to carry out test of conveyor width adjustment.
RETURN : Press to return to Page 515/000.
Note: For details refer to the HELPS Operation Manual.
• Explanation
This command is only displayed for HELPS-compatible machines.
Input the ID code which is set in Proper data.
Chapter 3 Description of Commands
515-210
515-220
Part 3
3 - 36
Version 2.0 GL-541E Operation
LMS Changing the LMS Settings 515-2
FUJI
Off line
Page 515-2
RETURNADJ. TESTCODE READINITIALIZECELL STAT
Command path:
GL_541E Prod 0000 Sche 00000
LMS
id code
[SET] - [STATUS] - [LINE] - [LMS]
• Action of the function keys To page
Press this function key to change the cell status.
UNIT : The machine reports board type information to the LMS.
ACTIVE CELL : The machine does not report board type information to the LMS. After
sending out a reservation the LMS issues changeover permission.
PASSIVE CELL : The machine does not report board type information to the LMS and does
not receive changeover permission from the LMS.
Note: Current cell status displays on the screen.
Chapter 3 Description of Commands
Part 3
3 - 37
Version 2.0 GL-541E Operation
CELL STAT Changing the Cell Status 515-210
FUJI
Off line
Page 515
PASSIVE CELLACTIVE CELLUNIT
Command path:
GL_541E Prod 0000 Sche 00000
CELL STAT
[SET] - [STATUS] - [LMS] - [CELL STAT]
• Action of the function keys
