RETURN : Press to return to page 300-000. • START button When the START button is pressed, the main conveyor moves to the loading position. The system determines whether or not a board is on the conveyor and then unloads…
UNLOAD PCB : Press to unload a board from the main conveyor.
LOAD PCB : Press to unload a board from the main conveyor and load a new
board.
LOAD PSTN : This function key displays when the main conveyor is not at the
loading position. Press to return the main conveyor to the load
position.
LIFTER▲ (LIFTER▼ ): This function key displays when the main conveyor is at the
loading position. Press to raise (lower) the lifter.
LOCK (UNLOCK): This function key displays when the main conveyor is at the
loading position. Press this to couple (uncouple) the in-
conveyor, main conveyor and out-conveyor.
PIN▲ (PIN▼) : This function key displays when the main conveyor is at the loading
position. Press to raise (lower) the reference pin.
RETURN : Press to return to page 000-000.
Chapter 3 Description of Commands
310-00
320-000
330-000
000-000
Part 3
3 - 20
Version 2.0 GL-541E Operation
LOADER Operating the loader 300-000
FUJI
Off line
Page 300
RETURN
PINLOCK
LOAD PSTN
LIFTER
LOAD PCB
LOAD PCB
UNLOAD PCB
UNLOAD PCB
Command path:
GL_541E Prod 0000 Sche 00000
LOADER
Board loader
[LOADER]
• Action of the function keys To page
RETURN : Press to return to page 300-000.
• START button
When the START button is pressed, the main conveyor moves to the loading position. The system
determines whether or not a board is on the conveyor and then unloads any board on the conveyor.
When the operation is complete, the display returns to page 300-000.
Chapter 3 Description of Commands
300-000
Part 3
3 - 21
Version 2.0 GL-541E Operation
Press START
UNLOAD PCB Unloading boards 310-000
FUJI
Off line
Page 310
RETURN
Command path:
GL_541E Prod 0000 Sche 00000
UNLOAD PCB
Unloading
[LOADER] - [UNLOAD PCB]
• Action of the function keys To page
RETURN : Press to return to page 300-000.
• START button
When the START button is pressed, the main conveyor moves to the loading
position. The system determines whether or not a board is on the conveyor and then
unloads any board on the conveyor. A new board is then loaded from the in-
conveyor. When the operation is complete, the display returns to page 300-000.
Chapter 3 Description of Commands
300-000
Part 3
3 - 22
Version 2.0 GL-541E Operation
Press START
LOAD PCB Loading New Boards 320-000
FUJI
Off line
Page 310
RETURN
Command path:
GL_541E Prod 0000 Sche 00000
LOAD PCB
Unloading
[LOADER] - [LOAD PCB]
• Action of the function keys To page
