Appendix A Chapter 1 Input Port Display A - 2 V ersion 2.0 X010 F1 Function key F1 X011 F2 Function key F2 X012 F3 Function key F3 X013 F4 Function key F4 X014 F5 Function key F5 X015 F6 Function key F6 X016 X017 - (MINU…
Appendix A
Chapter 1 Input Port Display
A - 1Version 2.0
X000 EMERGENCY SW Emergency stop button
X001 START SW Start button
X002 RESET SW Reset button
X003 CYCLE STOP SW Cycle stop button
X004 (RESERVED)
X005 (RESERVED)
X006
X007
X008 INCHING RIGHT Inching right key
X009 INCHING LEFT Inching left key
X00A INCHING DOWN Inching down key
X00B INCHING UP Inching up key
X00C INCHING CW Inching clockwise key
X00D INCHING CCW Inching counterclockwise key
X00E
X00F SHIFT KEY Shift key
1. Input Port Display
LED No. Display Description
Input 1
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
A - 2Version 2.0
X010 F1 Function key F1
X011 F2 Function key F2
X012 F3 Function key F3
X013 F4 Function key F4
X014 F5 Function key F5
X015 F6 Function key F6
X016
X017 - (MINUS KEY) Minus key
X018 E1 Axis change 1 (E1)
X019 E2 Axis change 2 (E2)
X01A E3 Axis change 3 (E3)
X01B E4 Axis change 4 (E4)
X01C TENKEY 1 Numeric input key 1
X01D TENKEY 2 Numeric input key 2
X01E TENKEY 4 Numeric input key 4
X01F TENKEY 8 Numeric input key 8
LED No. Display Description
Input 1
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
Version 2.0 A - 3
X020 MACHINE READY Machine ready for operation
X021 AIR OK Air pressure check switch
X022
X023 SERVO OK Servo ready
X024 TABLE READY Table movement OK 1
X025 LIFTER READY Table movement OK 2
X026 (RESERVE) Short circuit
X027 (RESERVE) Short circuit
X028 FRONT DOOR OK Door safety switch
X029
X02A LOADER PLC OK Board loader PLC OK
X02B
X02C
X02D (RESERVE)
X02E
X02F
LED No. Display Description
Input 2
GL-541E Operation
