RETURN : All function keys are disabled until the carriage return [CR] key is pressed. Press the backspace [BS] key to move the cursor back to re-enter an incorrect input. Press to return to page 000-000. • Explanation U…

100%1 / 261
CHANGE : Press to change the production program.
QTY. SET : Press to set the scheduled production quantity.
QTY. CLEAR : Press to set the number of boards produced to zero on the current
production program.
SKIP : Press to skip selected blocks.
RETURN : Press to return to page 000-000.
• Explanation
When this command is selected, all the programs currently stored in the machine are displayed.
Chapter 3 Description of Commands
410-000
420-000
440-000
000-000
Part 3
3 - 24
Version 2.0 GL-541E Operation
# PROGRAM NAME Sche
1 FUJI 00010
2 NEXT 00010
3" "
9 ***** *
PROGRAM Changing the Production Program 400-000
FUJI
Off line
Page 400
RETURNSKIPQTY. CLEARQTY. SET
CHANGE
Command path:
GL_541E Prod 0000 Sche 00000
Program?
[PROGRAM]
• Action of the function keys To page
RETURN : All function keys are disabled until the carriage return [CR] key is
pressed. Press the backspace [BS] key to move the cursor back to
re-enter an incorrect input. Press to return to page 000-000.
• Explanation
Using the numerical keypad, input the number of the program and press [CR].
Chapter 3 Description of Commands
000-000
Part 3
3 - 25
Version 2.0 GL-541E Operation
# PROGRAM NAME Sche
1 FUJI 00010
2 NEXT 00010
3" "
9 ***** *
CHANGE Changing the Production Program 410-000
FUJI
Off line
Page 410
RETURNSKIPQTY. CLEARQTY. SETCHANGE
Command path:
GL_541E Prod 0000 Sche 00000
CHANGE
Program no?
[PROGRAM] - [CHANGE]
• Action of the function keys To page
RETURN : All function keys are disabled until the carriage return [CR] key is
pressed. Press the backspace [BS] key to move the cursor back to
re-enter an incorrect input. Press to return to page 000-000.
• Explanation
Using the numerical keypad, input the number of boards to be produced under the current
production program. Input a number between 1 and 30,000 and press [CR] to execute the change.
Production will continue indefinitely if 0 is entered.
Chapter 3 Description of Commands
000-000
Part 3
3 - 26
Version 2.0 GL-541E Operation
QTY. SET Changing the Production Quantity 420-000
FUJI
Off line
Page 420
Command path:
GL_541E Prod 0000 Sche 00000
QTY. SET
Prod. Quantity
[PROGRAM] - [QTY. SET]
• Action of the function keys To page
