NOW POS : Press to start measurement from a random position. DEFAULT POS : Press to start measurement from the position specified in Proper data. For reverse board flow machine, measurement starts from the left. Note: Wh…
NOW POS : Press to start measurement from a random position.
DEFAULT POS : Press to start measurement from the position specified in
Proper data. For reverse board flow machine,
measurement starts from the left.
Note: When one of these function keys is pressed, the current G data displays.
RETURN : Press to return to Page 520.
• START button
The START button is enabled after the measurement start position is specified. When the START
button is pressed, glue is dispensed in the needle center measurement area and the position of the
glue dots is inspected by the camera.
Chapter 3 Description of Commands
524-210
524-210
Part 3
3 - 71
Version 2.0 GL-541E Operation
twin Needle Real-G50
Z2 Setting Z2 Needle Offset Starting Position 524-200
FUJI
Off line
Page 524
RETURNDEFAULT POSNOW POS
Command path:
GL_541E Prod 0000 Sche 00000
Z2
[SET] - [MANUAL] - [NEEDLE] - [Z2]
• Action of the function keys To page
NOW POS : Press to start measurement from a random position.
DEFAULT POS : Press to start measurement from the position specified in
Proper data. For reverse board flow machine,
measurement starts from the left.
Note: When one of these function keys is pressed, the current G data displays.
RETURN : Press to return to Page 520.
• START button
The START button is enabled after the measurement start position is specified. When the START
button is pressed, glue is dispensed in the needle center measurement area and the position of the
glue dots is inspected by the camera.
Chapter 3 Description of Commands
524-210
524-210
Part 3
3 - 72
Version 2.0 GL-541E Operation
twin Needle Real-G50
Z3 Setting Z3 Needle Offset Starting Position 524-200
FUJI
Off line
Page 524
RETURNDEFAULT POSNOW POS
Command path:
GL_541E Prod 0000 Sche 00000
Z3
[SET] - [MANUAL] - [NEEDLE] - [Z3]
• Action of the function keys To page
MEMORY : Press to display the contents of the memory.
SERVO : Press to display the servo board memory.
TRACE : Press to display the trace data.
SYSTEM : Presently not supported.
ETC. MODE : Press to go to Page DBG-5.
RETURN : Press to return to Page 520
• Input from numerical keypad
Input the ID code set in the Proper data.
Chapter 3 Description of Commands
525
SRV
DBG-3
DBG-5
520
Part 3
3 - 73
Version 2.0 GL-541E Operation
MEMORY Displaying the Memory Contents BGA
FUJI
Off line
Page BGA
RETURNETC. MODESYSTEMTRACESERVOMEMORY
Command path:
GL_541E Prod 0000 Sche 00000
MEMORY
id code
[SET] - [MANUAL] - [MEMORY]
• Action of the function keys To page
