Press this function key to change the cell status. UNIT : The machine reports board type information to the LMS. ACTIVE CELL : The machine does not report board type information to the LMS. After sending out a reservatio…

CELL STAT : Press to change the cell status.

INITIALIZE : Press to clear the program changeover memory.

CODE READ : Press to carry out the code reader test.

ADJ. TEST : Press to carry out test of conveyor width adjustment.

RETURN : Press to return to Page 515/000.

Note: For details refer to the HELPS Operation Manual.

• Explanation

This command is only displayed for HELPS-compatible machines.

Input the ID code which is set in Proper data.

Chapter 3 Description of Commands

515-210

515-220

Part 3

3 - 36

Version 2.0 GL-541E Operation

LMS Changing the LMS Settings 515-2

FUJI

Off line

Page 515-2

RETURNADJ. TESTCODE READINITIALIZECELL STAT

Command path:

GL_541E Prod 0000 Sche 00000

LMS

id code

[SET] - [STATUS] - [LINE] - [LMS]

• Action of the function keys To page

Press this function key to change the cell status.

UNIT : The machine reports board type information to the LMS.

ACTIVE CELL : The machine does not report board type information to the LMS. After

sending out a reservation the LMS issues changeover permission.

PASSIVE CELL : The machine does not report board type information to the LMS and does

not receive changeover permission from the LMS.

Note: Current cell status displays on the screen.

Chapter 3 Description of Commands

Part 3

3 - 37

Version 2.0 GL-541E Operation

CELL STAT Changing the Cell Status 515-210

FUJI

Off line

Page 515

PASSIVE CELLACTIVE CELLUNIT

Command path:

GL_541E Prod 0000 Sche 00000

CELL STAT

[SET] - [STATUS] - [LMS] - [CELL STAT]

• Action of the function keys

Press this function key to clear the ID station changeover memory. If for some reason the ID station

quits working then this key can be pressed to return it to its original status.

Note: As the status of changeover is usually stored in memory when the power supply to the machine is

cut off, refrain from pressing this key when it is not necessary.

Chapter 3 Description of Commands

Part 3

3 - 38

Version 2.0 GL-541E Operation

INITIALIZE Clearing Program Changeover Memory 515-220

FUJI

Off line

Command path:

GL_541E Prod 0000 Sche 00000

INITIALIZE

[SET] - [STATUS] - [LMS] - [CELL STAT] - [INITIALIZE]

• Explanation To page
