Appendix A Chapter 2 Input Port Display V ersion 2.0 A - 32 LY210 LOADER STATUS1 Loader status 1 LY211 LOADER STATUS2 Loader status 2 LY212 LOADER R/W Read/Write bit LY213 LOADER I/O In/Out bit LY214 LOADER PORT0 Port No…
Appendix A
Chapter 2 Input Port Display
Version 2.0 A - 30
SY010
SY011
SY012
SY013
SY014
SY015
SY016
SY017
SY018
SY019
SY01A
SY01B
SY01C
SY01D
SY01E
SY01F
LED No. Display Description
Servo Status Output 1
GL-541E Operation
Appendix A
Chapter 2 Input Port Display
A - 31Version 2.0
LY200 LOADER AUTO Board loader automatic operation
LY201 LOADER EMG Board loader emergency stop
LY202 LOADER CMD1 Board loader command 1
LY203 LOADER CMD2 Board loader command 2
LY204 LOADER CMD3 Board loader command 3
LY205 CLEAROFF REQ1 Board unload operation request 1
LY206 CLEAROFF REQ2 Board unload operation request 2
LY207 ID UNLOAD PERM MCID board unload permission
LY208 ID CONV NORMAL MCID conveyor motor forward rotation
request
LY209 ID CONV REV MCID conveyor motor reverse rotation
request
LY20A
LY20B
LY20C
LY20D
LY20E LOADER RESET Board loader alarm reset
LY20F DATA STROBE Data strobe
LED No. Display Description
Board Loader OP Link Output 1
GL-541E Operation
Appendix A
Chapter 2 Input Port Display
Version 2.0 A - 32
LY210 LOADER STATUS1 Loader status 1
LY211 LOADER STATUS2 Loader status 2
LY212 LOADER R/W Read/Write bit
LY213 LOADER I/O In/Out bit
LY214 LOADER PORT0 Port No 0
LY215 LOADER PORT1 Port No 1
LY216 LOADER PORT2 Port No 2
LY217 LOADER PORT3 Port No 3
LY218 LOADER DATA0 Output data 0 (2)
LY219 LOADER DATA1 Output data 1 (2)
LY21A LOADER DATA2 Output data 2 (2)
LY21B LOADER DATA3 Output data 3 (2)
LY21C LOADER DATA4 Output data 4 (2)
LY21D LOADER DATA5 Output data 5 (2)
LY21E LOADER DATA6 Output data 6 (2)
LY21F LOADER DATA7 Output data 7 (2)
LED No. Display Description
Board Loader OP Link Output 1
GL-541E Operation
