Appendix A
Chapter 1 Input Port Display
Version 2.0 A - 15
LX200 LOADER PLC OK Board loader PLC OK
LX201 LOADER ALARM1 Board loader alarm 1
LX202 LOADER ALARM2 Board loader alarm 2
LX203 LOADER CMPLT Board loading operation complete
LX204 CLEAROFF CMPLT Board unloading operation complete
LX205 PCB WAIT Board waiting
LX206 NEXT WAIT Waiting for next stage
LX207 LOADER WORK Board loader operating
LX208 MAIN PCB CHK Main conveyor board check
LX209 IN PCB CHK In-conveyor board check
LX20A ID PCB OUT MCID board unloading complete
LX20B ID PCB CHK1 MCID board check
LX20C ID PCB CHK2 MCID reverse board check
LX20D W. CONV PERMIT Conveyor width change permission
LX20E LOADER ALARM3 Board loader alarm 3
LX20F
LED No. Display Description
Board Loader OP Link Input 1
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
A - 16Version 2.0
LX210
LX211
LX212
LX213
LX214
LX215
LX216
LX217 DATA STROBE Data set complete
LX218 LD I/O DATA0 Input data 0
LX219 LD I/0 DATA1 Input data 1
LX21A LD I/0 DATA2 Input data 2
LX21B LD I/0 DATA3 Input data 3
LX21C LD I/0 DATA4 Input data 4
LX21D LD I/0 DATA5 Input data 5
LX21E LD I/0 DATA6 Input data 6
LX21F LD I/0 DATA7 Input data 7
LED No. Display Description
Board Loader OP Link Input 1
GL-541E Operation
Appendix A
Chapter 2 Input Port Display
A - 17Version 2.0
Y000 START LAMP ON Lamp in START button is on
Y001 RESET LAMP ON Lamp in RESET button is on
Y002 BUZZER ON Buzzer on
Y003
Y004
Y005
Y006
Y007
Y008 RED LIGHT Signal tower red light
Y009 YELLOW LIGHT Signal tower yellow light
Y00A BLUE LIGHT Signal tower blue light
Y00B RED FLASH Signal tower red light flashing
Y00C YELLOW FLASH Signal tower yellow light flashing
Y00D BLUE FLASH Signal tower blue light flashing
Y00E (USER DEFINE1) User defined 1
Y00F (USER DEFINE1) User defined 2
2. Output Port Display
LED No. Display Description
Output 1
