Chapter 1 T able of Proper Data Part 4 GL-541E Operation 4 - 10 V ersion 2.0

100%1 / 261
$ 252 . MG4S129 spare = 0
$ 253 . MG4S130 spare = 0
# 254 . MG4GCPX glue_check_orgn_position_x = 36500
# 255 . MG4GCPY glue_check_orgn_position_y = 39200
%* 256 . MG4NOXZ1 Needle_offset_X_Z1 = 0
%* 257 . MG4NOXZ2 Needle_offset_X_Z2 = 0
%* 258 . MG4NOXZ3 Needle_offset_X_Z3 = 0
%* 259 . MG4NOYZ1 Needle_offset_Y_Z1 = 0
%* 260 . MG4NOYZ2 Needle_offset_Y_Z2 = 0
%* 261 . MG4NOYZ3 Needle_offset_Y_Z3 = 0
%* 262 . MG4NOQZ1 Needle_offset_Q_Z1 = 0
%* 263 . MG4NOQZ2 Needle_offset_Q_Z2 = 0
%* 264 . MG4NOQZ3 Needle_offset_Q_Z3 = 0
# 265 . MG4ZUAZ1 Z_up_app_Z1 = 600
# 266 . MG4ZUAZ2 Z_up_app_Z2 = 600
# 267 . MG4ZUAZ3 Z_up_app_Z3 = 600
$ 268 . MG4S133 spare = 0
$ 269 . MG4S134 spare = 0
$ 270 . MG4S135 spare = 0
%* 271 . MG4MCPX Mark_camera_pixel_X = 1152000
%* 272 . MG4MCPY Mark_camera_pixel_Y = 1228800
%* 273 . MG4MCRO Mark_camera_Rotation = 0
$ 274 . MG4MCGA Mark_camera_gain = 0
$ 275 . MG4MCOF Mark_camera_offset = 0
$ 276 . MG4GCGA Glue_camera_gain = 0
$ 277 . MG4GCOF Glue_camera_offset = 0
Attr Name Value
4 - 9
Version 2.0
Chapter 1 Table of Proper Data
Part 4
GL-541E Operation
Chapter 1 Table of Proper Data
Part 4
GL-541E Operation
4 - 10
Version 2.0
Chapter 2 Explanation of Proper Data
2. Explanation of Proper Data
1. MG4ID ID_Code
This identification code acts as a password to limit access to certain command
operations. The user selects up to eight digits to serve as this code.
Standard setting: Choose a number of no more than eight digits.
2. MG4LG Language = 0
Selects the language for the displays.
English [0]
Japanese [1]
3. MG4REL Red_Light = 1024
Signal tower red lamp lighting conditions (16-bit binary data).
Standard setting: 1024 (0000 01000 0000 0000) Vision processing error.
The settings for the signal tower Proper data items are input as a decimal number
(a 16 bit mask pattern). The bits are numbered as indicated below.
The bit settings required to light the tower or to make it flash in various situations are
indicated in the following table.
Bit Setting Status
15 1000 0000 0000 0000 Not used at present
14 0100 0000 0000 0000 Temperature regulator alarm
13 0010 0000 0000 0000 Machine stopped after completing schedule
12 0001 0000 0000 0000 Not used at present
11 0000 1000 0000 0000 Changeover operator call
10 0000 0100 0000 0000 Vision processing error
9 0000 0010 0000 0000 Performing automatic operation
8 0000 0001 0000 0000 Performing loader cycle
7 0000 0000 1000 0000 Board wait mode
6 0000 0000 0100 0000 Waiting to unload a board (waiting for next stage)
5 0000 0000 0010 0000 Parts out warning (not used on GL)
4 0000 0000 0001 0000 Machine stopped due to parts out (not used on GL)
3 0000 0000 0000 1000 Machine stopped due to error
2 0000 0000 0000 0100 Statistical error alarm
1 0000 0000 0000 0010 Machine stopped due to changeover
0 0000 0000 0000 0001 Machine stopped for reason not listed above
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
(15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0)
4 - 11
Version 2.0
GL-541E Operation
Part 4
