Part 5 5 - 1 1 V ersion 2.0 Chapter 4 V ision T est Mode 4. V ision T est Mode The vision test can be used to individually inspect the fiducial marks and block skip marks. The objective of the vision test is to reduce pr…

Chapter 3 Adjustment Mode

Part 5

3.1.1 Real Image Display

The actual image at the selected camera is displayed on the vision processing

monitor using the [DSP REAL-IMG] command.

3.1.2 Image Acquisition and Display

The image is acquired by the selected camera using the [GET ACQ] command.

The previously acquired image is displayed at the vision processing monitor

using the [Acquired IMG] command.

The status of the acquired image is checked using this command.

In addition the following operations can be performed on the displayed image

using the commands (F1~F6) shown below.

ZOOM IN: Enlarges the displayed image.

ZOOM OUT: Reduces an image that has been enlarged.

The image acquired by the mark camera cannot be reduced

to a size smaller than the size of the image when it was

acquired.

SCROLL: The image can be scrolled up and down or left and right

using the scroll commands.

<<<<< Moves the image to the left.

>>>>> Moves the image to the right.

▲ Moves the image up.

▼ Moves the image down.

STEP Specifies the number of pixels the image

moves each time one of the scroll commands

is pressed.

10 -> 25 -> 50 -> 100 -> 10 [Pixel]

RETURN: Returns to the previous page.

F1 F2 F4 F5 F6

ZOOM IN ZOOM OUT

SCROLL

RETURN

5 - 10

Version 2.0

GL-541E Operation

Part 5

5 - 11

Version 2.0

Chapter 4 Vision Test Mode

4. Vision Test Mode

The vision test can be used to individually inspect the fiducial marks and block skip marks.

The objective of the vision test is to reduce problems associated with vision processing during

production by processing the fiducial marks prior to production in order to make sure the data

is correct and to verify that vision processing is in fact possible.

The vision test is selected using the [SET] -> [MANUAL] -> [VISION] -> [VISION TEST]

command sequence.

The function keys (F1~F6) shown below display when the [VISION TEST] command is

selected.

Note: The display returns to the previous page if the [RETURN] key is pressed.

4.1 Fiducial Mark Vision Test

The fiducial marks used in the production program in the foreground of the machine are

inspected using the mark coordinate information in sequence data and mark data.

The function keys (F1~F6) shown below display when the [F MARK] command is

selected.

Note (1) Refer to chapter 2 for details of the trace command section.

(2) If the [RETURN] key is pressed the screen will return to the previous page.

F1 F2 F4 F5 F6

RETURNSET DATA TRACE FORM DSPLY DSP REAL IMG VP. EXE

F1 F2 F4 F5 F6

RETURNFMARK BMARK

GL-541E Operation

Chapter 4 Vision Test Mode

Part 5

4.1.1 Setting the Mark Data

The relevant mark data must be specified in order to carry out the mark reading

vision test.

Specify the sequence number after selecting the [SET DATA] command.

Use the numeric keypad to input the sequence number of the mark read

sequence (mask mark read sequence or board mark read sequence) for which the

vision test is to be carried out.

The data for the specified mark sequence displays when this input is complete.

4.1.2 Mark Form Display

The mark form cannot be displayed if the mark data is not set.

The form display function is used to check whether the mark for which data has

been set is the same as the registered mark (for example are the marks the same

color).

The form of the mark for which data has been set is displayed at the vision

processing monitor using the [FORM DSPLY] command.

Note that the form that displays is the form of the mark that is registered in the

vision processing board.

Note: Vision processing system version V2.70 or later is necessary to execute the

[FORM DSPLY] command.

4.1.3 Real Image Display

The real image display function is used to verify by how much the mark is

displaced when a mark read error occurs.

The real image is displayed at the vision processing monitor using the

[DSP REAL-IMG] command.

5 - 12

Version 2.0

GL-541E Operation
