SPEED : Press to change the rapid inching speed. CONV. WIDTH : Press to change and set the conveyor width. This function key only displays when the automatic conveyor width adjustment is available. DISPLAY CHG : Press to…
SET : Press to measure the loader Y-axis coordinates. The display
returns to Page 530 after measurement is complete.
RETURN : Press to return to Page 530
• Explanation
L_pos flashes in the first display area.
Chapter 3 Description of Commands
530
530
Part 3
3 - 97
Version 2.0 GL-541E Operation
Proper
X0 : 15710 Y0 : 621
Xc_1 : 7038 Yc_1 : -1708
Xc_2 : 13540 Yc_2 : -1706
Xc_3 : 8040 Yc_3 : -1710
X0 : 15170 Y0 : 621
Z0_1 : 283
Z0_2 : 254
Z0_3 : 265
L_pos : 8735
LOAD PSTN Measuring Loader Proper Data 535
FUJI
Off line
Page 535
RETURNSET
Command path:
GL_541E Prod 0000 Sche 00000
PROPER
Ready
[SET] - [PROPER] - [LOAD PSTN]
• Action of the function keys To page
SPEED : Press to change the rapid inching speed.
CONV. WIDTH : Press to change and set the conveyor width. This function
key only displays when the automatic conveyor width
adjustment is available.
DISPLAY CHG : Press to toggle the servo count display between Cartesian
coordinates and servo coordinates.
RETURN : Press to return to Page 530.
Note: The servo counter remains displayed if the rapid inching key [F] and the [RETURN] function keys
are pressed simultaneously.
Chapter 3 Description of Commands
541
542
530
Part 3
3 - 98
Version 2.0 GL-541E Operation
Servo Counter
000000 pls
000000 pls
000000 pls
000000 pls
000000 pls
000000 pls
World (Zero)
SERVO Making Servo Settings 540
FUJI
Off line
Page 540
RETURNDISPLAY CHGCONV. WIDTHSPEED
Command path:
GL_541E Prod 0000 Sche 00000
SERVO
[SET] - [SERVO]
• Action of the function keys To page
X : Press to change the inching speed of the X-axis.
Y : Press to change the inching speed of the Y-axis.
Q : Press to change the inching speed of the θ-axis.
Z : Press to select the Z-axis for which the inching speed is to be
changed.
RETURN : Press to return to Page 540.
• Input from numerical keypad
The rapid inching speed can be changed by inputting the desired speed with the numerical keys.
For each axis input the speed as a percent of the maximum speed during automatic operation.
Input a value in the range from 1 to 100. The speed increases as the setting is increased.
Chapter 3 Description of Commands
541-100
540
Part 3
3 - 99
Version 2.0 GL-541E Operation
(The inching speed for each axis displays here.)
SPEED Changing the Rapid Inching Speed 541
FUJI
Off line
Page 541
RETURNZQYX
Command path:
GL_541E Prod 0000 Sche 00000
INCHING SPEED
Ready
[SET] - [SERVO] - [SPEED]
• Action of the function keys To page
