Appendix A Chapter 1 Input Port Display A - 8 V ersion 2.0 X070 HEAT ALRM Heater alarm X071 X072 X073 TMP STBLZ ‘G Specified temperature X074 X075 X076 X077 X078 X079 X07A X07B X07C X07D X07E X07F LED No. Display Descrip…
Appendix A
Chapter 1 Input Port Display
Version 2.0 A - 7
X060
X061
X062
X063
X064
X065
X066
X067
X068
X069
X06A
X06B
X06C
X06D
X06E
X06F
LED No. Display Description
Input 4
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
A - 8Version 2.0
X070 HEAT ALRM Heater alarm
X071
X072
X073 TMP STBLZ ‘G Specified temperature
X074
X075
X076
X077
X078
X079
X07A
X07B
X07C
X07D
X07E
X07F
LED No. Display Description
Input 4
GL-541E Operation
Appendix A
Chapter 1 Input Port Display
Version 2.0 A - 9
LX000 LOADER EMG Loader emergency stop
LX001 PCB AVAILABLE Board available signal from previous stage
LX002 PCB REQ Board request signal from next stage
LX003
LX004 IN ARRV CHK In-conveyor board arrival
LX005 IN STPR ON In-conveyor stopper on
LX006 IN STPR OFF In-conveyor stopper off
LX007
LX008
LX009 MAIN ARRV CHK Main conveyor board arrival
LX00A MAIN STPR ON Main conveyor stopper up
LX00B MAIN STPR OFF Main conveyor stopper down
LX00C PCB OUT CHK Board unload check
LX00D OUT ARRV CHK Out-conveyor board arrival check
LX00E
LX00F
LED No. Display Description
Board Loader PLC Input 1
GL-541E Operation
